Specifications
API SPEC 5CT Standard.Steel grade: J5Size: 4 1/2~20 for Seamless Casing
Length: R1/R2/R3
Standard API SPEC 5CT Standard.
Use Seamless steel tubes for oil casing and tubing in oil and gas well. Casing pipe is the steel pipe to support the wall of oil and gas wells, divided into surface casing, protective casing and production casing.
Steel grade J55, K55, N80, L80, C90, T95, P110, Q125
Size 4 1/2”~20” for Seamless Casing
Length R1/R2/R3
Standard |
Models of steel tubes |
Tensile strength (MPa) |
Yield strength (MPa) |
Elongation (%) |
Hardness |
API SPEC 5CT |
J55 |
≥517 |
379~552 |
check the table |
≤241HB |
K55 |
≥517 |
≥655 |
|||
N80 |
≥689 |
552~758 |
|||
L80(13Cr) |
≥655 |
552~655 |
|||
P110 |
≥862 |
758~965 |
Standard |
Models of steel tubes |
Chemical compositions (%) |
||||||||||
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Cu |
Mo |
V |
Als |
||
API SPEC 5CT |
J55K55 (37Mn5) |
0.34~ 0.39 |
0.2~ 0.35 |
1.25~ 1.5 |
≤0.02 |
≤0.015 |
≤0.15 |
≤0.20 |
≤0.20 |
|
|
≤0.02 |
N80 (36 Mn2V) |
0.34~ 0.38 |
0.2~ 0.35 |
1.45~ 1.7 |
≤0.02 |
≤0.015 |
≤0.15 |
|
|
|
0.11~ 0.16 |
≤0.02 |
|
L80 (13Cr) |
0.15~ 0.22 |
≤1.0 |
0.25~ 1.0 |
≤0.02 |
≤0.010 |
12.0~ 14.0 |
≤0.20 |
≤0.20 |
|
|
≤0.02 |
|
P110 (30CrMo) |
0.26~ 0.35 |
0.17~ 0.37 |
0.40~ 0.7 |
≤0.02 |
≤0.010 |
0.8~1.1 |
≤0.20 |
≤0.20 |
0.15~ 0.25 |
≤0.08 |
≤0.02 |
|
Note: Also we can supply you pup joint and coupling (coupling stock and coupling blank) for tubing and Casing, as well as for weld pipe.
