We offers a complete range of high performance innovative float equipment for your downhole cementing operations.
A variety of Float Shoes and Float Collars have been designed for various downhole operating conditions.
Technical specifications and parameters for Float collar & Float shoe | |||||||
Specification |
O.D.(mm) |
Total length(mm) |
I.D.(mm) |
Min. Dia. (mm) |
Connection Type |
Affordable strength of back-pressure (Mpa) |
|
Float collar |
5 |
141.3 |
500 |
110 |
50 |
5 BCSG |
35 |
5 1/2 |
153.67 |
530 |
112 |
55 |
5 1/2 BCSG |
35 |
|
7 |
194.46 |
586 |
162.5 |
77 |
7 BCSG |
35 |
|
9 5/8 |
270 |
720 |
225 |
77 |
9 5/8 BCSG |
35 |
|
13 3/8 |
365 |
720 |
319 |
77 |
13 3/8 BCSG |
35 |
|
20 |
533.4 |
720 |
475 |
77 |
20 BCSG |
35 |
|
Float shoe |
5 |
140.3 |
495 |
110 |
50 |
5 BCSG |
35 |
5 1/2 |
153.67 |
514 |
122 |
55 |
5 1/2 BCSG |
35 |
|
7 |
194.46 |
533 |
162.5 |
77 |
7 BCSG |
35 |
|
9 5/8 |
269.88 |
550 |
225 |
77 |
9 5/8 BCSG |
35 |
|
13 3/8 |
339.7 |
550 |
319 |
77 |
13 3/8 BCSG |
35 |
|
20 |
534 |
652 |
475 |
77 |
20 BCSG |
35 |
|
