Specifications
1.API SPEC 11E standard2.Reliable performance, simple structure
3.Easy operation and maintenance
Application:
This kind of pumping unit adopts symmetrical sheave structure. Work over operation can be carried out by simply removing the carrier bar beam. The small sheave is connected with the crank pin through wire line and crossbeam does not need. The small sheave is designed as an involute shape and the big sheave is designed as a circular shape. During each stroke, the variation principle of the sheave radius ratio is incompliance completely with that of the polished rod load. Thus the peak torque of the reducer output shaft is lowered and energy saved.
Main Feature:
Simple structure and tight, light weight. The electricity saving about 25% compare to normal pumping unit.
Standard: API SPEC 11E standard.
Involute Pumping unit
Technical specifications and parameters for Involute Pumping Unit | ||||||
Model |
Reducer Rating |
Structure Capacity (Kn.m) |
Stroke Frequency (min-1) |
Stroke Length(m) |
Motor Power (Kw) |
Unit Weight (t) |
CYJJ10-5-37HB |
37 |
100 |
5,4.2,3.6 |
4,5,6 |
22 |
21.5 |
CYJJ12-5-53HB |
53 |
120 |
5,4.2,3.6 |
4,5,6 |
37 |
23.2 |
