Home > Manufacturing & Processing Machinery > Mining Machinery > Mining Machinery Parts > Well Drilling Subsurface Sucker Rod Pump

Well Drilling Subsurface Sucker Rod Pump

Name: Well Drilling Subsurface Sucker Rod Pump
Brand: Senwell
SKU: 123854425

Well Drilling Subsurface Sucker Rod Pump thumbnail-1

Well Drilling Subsurface Sucker Rod Pump photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

Senwell

Type:

Other, Sucker rod pump

Contact Supplier Request Quote Chat Now

Shaanxi Senwell Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China main ports

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name Senwell

Type Other, Sucker rod pump

Machine Type Other, Oil mining equipment

Certification API

Use Well Drilling

Specifications

API Spec 11AX standard

Function:

The inner surface of the pump barrel is processed with carbonization quench and chrome plating technology and the plunger surface is processed with thermal metal spraying technology. The pump meets the requirement of long stroke. High speed and deep producing and has the advantages of high pumping efficiency. Large displacement, wear and corrosion resistance, long operation and easy repairing.

Technical specifications and parameters for Pump Bore (basic) and Designation
Pump Bore (basic)		112	125	150	175	200	225	250	275	325	375	425
Pump Bore Dia.	Normal mm	28	32	38	44	51	57	64	70	83	95	108
	Normal mm
	Basic mm(in)	28.575	31.75	38.10	44.45	50.80	57.15	63.50	69.85	82.55	95.25	107.95

Clearance Code and Clearance Fit Range

Clearance Grade	Pump Bore Deviation	Metal Plunger			Clearance Range mm(in)
Clearance Grade	Pump Bore Deviation	Code	Basic size(mm)	Limit-Deviation	Clearance Range mm(in)
1	D₀^+0.05	1	d-0.025	0~0.013	0.025-0.088
2		2	d-0.050		0.050-0.113
3		3	d-0.075		0.075-0.138
4		4	d-0.100		0.100-0.163
5		5	d-0.125		0.125-0.0075
