Help CenterPetroleum Thermal Recovery Wellhead and Christmas Tree
Related Products
-
Double-channel Thermal Recovery Wellhead EquipmentNegotiableMOQ: 1 Piece -
Petroleum Double-channel Thermal Recovery Wellhead EquipmentNegotiableMOQ: 1 Piece
-
High Pressure and Anti-sulfide Wellhead and Christmas Tree MachineNegotiableMOQ: 1 Piece
-
Petroleum High Pressure and Anti-sulfide Wellhead and Christmas TreeNegotiableMOQ: 1 Piece
-
Hollow Sucker RodsNegotiableMOQ: 1 Piece
Specifications
API SPEC 6A standardFunction:
KR thermal recovery wellhead & X-mas tree is mainly used in wells using steam stimulation or other thermal recovery methods.
Valve body, valve cover ,valve plate, valve stem and so on are made of materials with good high temperature creep resistance, the valves can operate at temperature up to 370°C(698°F)and open or close under high pressure and high temperature without any deformation, Even at 370°C,the seal rings can still maintain good sealing performance.
Standard: API SPEC 6A standard.
Detailed specification:
Technical specifications and parameters for Thermal Recovery Wellhead & X-max tree | |||
Type |
KR65-21 |
KR78-21 |
KR65-35 |
Nominal Diameter(in) |
2 9/16 |
3 1/16 |
2 6/16 |
Working pressure |
3000psi |
3000psi |
5000psi |
Working Temperature |
0°F~698°F |
0°F~698°F |
0°F~698°F |
Connection type |
Clamp & Flange |
Flange |
Flange |
Size of connecting casing |
5 1/2” or 7” |
5 1/2” or 7” |
5 1/2” or 7” |
External Dimension(L×H) |
60 × 52 |
161 × 55 |
73 × 80 |
Weight |
1430lbs |
2200lbs |
2816lbs |
