Help CenterNormal Wellhead and Christmas Tree Equipment
Related Products
-
API 6A Normal Wellhead and Christmas TreeNegotiableMOQ: 1 Piece -
Petroleum Offshore Wellhead and Christmas TreeNegotiableMOQ: 1 Piece
-
Offshore Wellhead and Christmas Tree MachineNegotiableMOQ: 1 Piece
-
Water Injection Wellhead and Christmas Tree MachineryNegotiableMOQ: 1 Piece
-
API 6A Water Injection Wellhead and Christmas Tree EquipmentNegotiableMOQ: 1 Piece
Specifications
API SPEC 6A standardFunction:
KY65-21 wellhead & X-mas tree comes in two types for flowing wells and pumping wells. For wells that can flow themselves and pressure at welhead are not more than 25MPa, flowing wellhead can be used. For pumping wells, pumping welhead can be used. Flowing wellhead can be converted into pumping wellhead conveniently only by replacing the tee, cross and polished rod stuffing box.
The product has advantages of fast in installation, reliable in seal and beautiful in appearance.
KY65-35 wellhead & X-mas tree uses flanges for connection. It has the advantages such as easy in installation, fast in dismantling, reliable in seal both under low pressure and high pressure and long in working life.
Standard: API SPEC 6A standard.
Detailed specification:
Technical specifications and parameters for Normal Wellhead & X-max tree | |||
Type |
KY65-21 |
KR65-35 |
|
Flowing wellhead |
Pumping wellhead |
||
Nominal Diameter(in) |
2 9/16 |
2 9/16 |
2 6/16 |
Working pressure |
3000psi |
3000psi |
5000psi |
Working Temperature |
20°F~180°F |
20°F~180°F |
20°F~180°F |
Connection type |
Clamp |
Clamp |
Flange |
Size of connecting casing |
5 1/2” or 7” |
5 1/2” or 7” |
5 1/2” or 7” |
External Dimension(L×H) |
59 × 47 |
59 × 47 |
89 × 69 |
Weight |
1100lbs |
968lbs |
2992lbs |
