API Oilfield Metal Seals Tubing Head With Flange

Name: API Oilfield Metal Seals Tubing Head With Flange
Brand: SENWELL
SKU: 123854065
Availability: InStock

Shaanxi Senwell Import & Export Co., Ltd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

China

Brand Name:

SENWELL

Type:

Other, Tubing head

Payment & Shipping

Payment Methods:

Port of Shipment:

China Main Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name SENWELL

Type Other, Tubing head

Machine Type Other, Oil Mining Equipment

Processing Type Forging

Use Well Drilling

Specifications

1.Top flange (in):7 1/16,9,11
2.Bottom flange (in):9, 11, 13 5/8
3.Side bore(mm):46, 52, 65
4.Vertical bore(mm):160,200,255

Tubing head

Tubing spool is used for hanging tubing and sealing the annular space between casing and tubing, features with the following:

Secondary seal between tubing hanger and adapter hanger can be “O” ring, grease injection BT seal or metal-metal seal:
Metal-metal seals, special elastomer seals, or metal + special elastomer seal are set between tubing hanger and tubing head.
Tubing hanger for tubing head has straight type seat bore and 45 cone of hanging shoulder, with strong loading ability.
Complete with lubricator and sealing test port.
Secondary seal mechanism is set at the bottom flange, which can be “O” seal, grease injection BT seal or metal seal.
Tubing hanger and tubing head adapter flange can be penetrated through by cable and be provide with subsurface safety valve which can control pipeline interface, exhaust pipeline interface, chemical agent injecting interface. When it is not used, it can be installed blind plugging.
The two end of tubing hanger can be set with tubing thread or gas sealing button and in the center it can ser with SPV thread as required
Top flanges are provided with locking screw.
The connection type of side outlet is bolted flange with VR thread for valve replacement operation.

Detail Specification:

Technical specifications and parameters for tubing head
Working pressure psi (Mpa)	Top flange (in)	Bottom flange (in)	Side bore(mm)	Vertical bore(mm)
2,000 3,000 5,000 10,000 15,000(105) 20,000(140)	7 1/16	9, 11, 13 5/8	46, 52, 65	160
	9	11, 13 5/8	46, 52, 65	200
	11	11, 13 5/8	46, 52, 65	255
