Specifications
1.delicate architecturenvenient transportation & installation
3.beefy cross-country capability
Coiled tubing unit is co-production by our company and a Holland company which is self-propelled operation equipment and composed of chassis, truck mounted operation unites, BOP stack and so on. The character of coiled tubing unit is as follow: delicate architecture, convenient transportation and installation, beefy cross-country capability, comfortable operation, large volume capacity, strong lifting ability and so on which make coiled tubing unit suitable for complex operational mode and road transport.
1. Main Technical Parameter:
Item |
Parameters |
Max. Capacity(1.25”CT,/m) |
11,280 |
(1.5”CT, /m) |
7,640 |
(1.75”CT,/m) |
5,570 |
(2” CT,/m) |
4,260 |
Drive mode |
8×8 |
Engine Power |
300kW/2100rpm (400hp/2100rpm) |
Outside Dimensions(L×W×H) |
12.0×2.55×4.00m |
Whole Quality (kg) |
54,000 |
Max Speed of Truck (km/h) |
83 |
Max. Climb Angle (Full Load) (%) |
45 |
Approach Angle (°) |
26 |
Departure Angle (°) |
16 |
Ground Clearance (Drum Lifting/mm) |
320 |
(Normal Speed Condition/mm) |
200 |
Min. turning diameter (m) |
32 |
Work Temperature |
-40°C-+50°C(-4°F-20°F) |
