Help CenterCoiled Tubing Unit
Related Products
Specifications
1.Delicate architecture2.Convenient transportation & installation
3.Beefy cross-country capability
4.Comfortable operation
Item |
Parameters |
Max. Capacity(1.25"CT,/m) |
11,280 |
(1.5"CT, /m) |
7,640 |
(1.75"CT,/m) |
5,570 |
(2" CT,/m) |
4,260 |
Drive mode |
8×8 |
Engine Power |
300kW/2100rpm (400hp/2100rpm) |
Outside Dimensions(L×W×H) |
12.0×2.55×4.00m |
Whole Quality (kg) |
54,000 |
Max Speed of Truck (km/h) |
83 |
Max. Climb Angle (Full Load) (%) |
45 |
Approach Angle (°) |
26 |
Departure Angle (°) |
16 |
Ground Clearance (Drum Lifting/mm) |
320 |
(Normal Speed Condition/mm) |
200 |
Min. turning diameter (m) |
32 |
Work Temperature |
-40°C-+50°C(-4°F-20°F) |
Technique Features:
1) Integrated design, delicate architecture, small turning radius, high operation efficiency, met little well site and fast installation/disassemble.
2) Chasses with sectionalized frame is assembled and welded with high intensity hot rolled steel plate, which is light and big load capacity; chassis is full wheel drive and cross-country capability is strong.
3) Elevating control cabin can clearly observe the coiled tubing and the injector head above well. All-weather assembled control room supplies clear and comfortable surrounding with high level insulation, HV (forceful electric power)/ electronic control board, advanced air-condition.
