CLF Type Reverse Circulation Fishing Magnet
Specifications
1.API thread2.CLF type
3.Equipped with permanent magnet iron
Function:
CLF type reverse circulation fishing magnet in petroleum and geology exploration is used for fishing of small fallen objects in the downhole.
Advantage:
With some of advantages such as simply structure, easy to operate, reliable performance, small size and light weight, it is a equipped with permanent magnet iron which can attract small objects such as teeth wheel, palm, tong teeth and tool so that small objects in down hole are fished and the well bottom is cleaned up.
Detail Specification:
Technical specification and parameters for Reverse circulation fishing magnet | |||||
Type |
O.D. (mm) |
Connection |
Attracted Weight (kg/cm2) |
Temperature in well |
Hole Size (mm) |
CLF89 |
89 |
NC26 |
9.8 |
210 |
95~100 |
CLF100 |
100 |
NC26 |
9.8 |
210 |
110~135 |
CLF125 |
125 |
NC38 |
9.8 |
210 |
135~165 |
CLF140 |
140 |
NC38 |
8.5 |
210 |
150~175 |
CLF146 |
146 |
NC38 |
8.5 |
210 |
160~185 |
CLF150 |
150 |
NC50 |
8.5 |
210 |
160~185 |
CLF175 |
175 |
NC50 |
7.9 |
210 |
185~210 |
CLF178 |
178 |
NC50 |
7.8 |
210 |
185~210 |
CLF190 |
190 |
NC50 |
7.8 |
210 |
200~225 |
CLF200 |
200 |
NC50 |
7.6 |
210 |
210~235 |
CLF203 |
203 |
NC50 |
7.6 |
210 |
215~240 |
CLF225 |
225 |
6 5/8REG |
7.5 |
210 |
235~270 |
CLF254 |
254 |
6 5/8REG |
7.0 |
210 |
265~311 |
CLF265 |
265 |
6 5/8REG |
6.9 |
210 |
275~330 |
CLF292 |
292 |
6 5/8REG |
6.9 |
210 |
300~442 |
CLF317 |
317 |
7 5/8REG |
6.9 |
210 |
340~375 |
CLF356 |
356 |
7 5/8REG |
6.9 |
210 |
444.5 |
