Home > Manufacturing & Processing Machinery > Mining Machinery > Mining Machinery Parts > 4 Rotary Table
4 Rotary Table
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Senwell
Type:
Other, Rotary table
Payment & Shipping
Payment Methods:
Port of Shipment:
China main ports
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Well Drilling Vertical Rotary TableNegotiableMOQ: 1 Set -
Horizontal and Vertical Universal Rotary TableNegotiableMOQ: 1 Set
-
1800kg-3900kg API Oil Driller Rotating Travelling Hook Blocks With Snubber AssemblyNegotiableMOQ: 1 Set
-
API Well Drilling Hook Blocks 1800kg-3900kg Rotating Travelling With Snubber AssemblyNegotiableMOQ: 1 Set
-
API Drilling Rig Traveling Blocks for Oil WellNegotiableMOQ: 1 Set
Place of Origin
China
Brand Name
Senwell
Type
Other, Rotary table
Machine Type
Other, Rig components
Use
Well Drilling
Specifications
API Spec 7K StandardProduct features
- Main and pinion gears are both made from alloy steel.
- The whole main bushing is cast steel.
- Could be put into the roller bushing of API standard kelly or hexagonal kelly, long or short slips are both adaptable.
- Fully lubricated and safely sealed
Parameters description
Technical specifications and parameters for Rotary Table | |||||
Type |
ZP175 |
ZP205 |
ZP275 |
ZP375 |
ZP495 |
Through hole Dia. mm(in) |
444.5 (17-1/2) |
520.7 (20-1/2) |
698.5 (27-1/2) |
952.5 (37-1/2) |
1257.3 (49-1/2) |
Center distance mm(in) |
1118 (44) |
1353 (53-1/4) |
1353 (53-1/4) |
1353 (53-1/4) |
1651 (65) |
Max static load (KN) |
1350 |
3150 |
4500 |
5850 |
7250 |
Max working torque (Nm) |
14000 |
23000 |
28000 |
33000 |
37000 |
Max Rpm (r/min) |
300 |
300 |
300 |
300 |
300 |
Dimension (L×W×H) (mm) |
1935×1280×585 |
2292×1475×668 |
2392×1670×685 |
2468×1810×718 |
2940×2184×813 |
Weight (kg) |
3888 |
5530 |
6163 |
7548 |
11626 |
