Home > Manufacturing & Processing Machinery > Mining Machinery > Mining Machinery Parts > Drilling Power Swivel Head

Drilling Power Swivel Head

Name: Drilling Power Swivel Head
Brand: Senwell
SKU: 123850075

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

Senwell

Type:

Other, Swivel

Contact Supplier Request Quote Chat Now

Shaanxi Senwell Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China main ports

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name Senwell

Type Other, Swivel

Machine Type Other, Rig components

Use Well Drilling

Specifications

Standard: API SPEC 8A

Main feature:
(1) Equipped with standard lifting bail and pin-to-pin alloy steel nipple.
(2) Conform to the industry standard SY/T5530
(3) Double pin (male) alloy sub is applied as requirements
(4) The wash pipe and packing assembly are cartridge type and can be replaced on the floor without disconnecting the rotary hose or gooseneck
(5) Equipped with rotary hose joint (4 API LP)

Standard: API SPEC 8A.

Detailed specification:

Technical specifications and parameters for Swivel
Type		SL135	SL160	SL170	SL225	SL450	LB140	CH125
Max static load (KN)		1350	1600	1700	2250	4500	1245	1250
Max Rpm (r/min)		300	300	300	300	300	300	300
Max. working pressure (Mpa)		27.5	35	35	35	35	27.5	21
Center tube drift diameter (mm)		60	57	70	75	75	60	68
Angle of Gooseneck and vertical line		15°	15°	15°	15°	15°	15°	15°
Tooling thread	Center tube	4 1/2 FH LH	4 1/2 REG LH	4 1/2 REG LH	6 5/8 REG -LH	6 5/8 REG LH	4 1/2 FH LH	4 1/2 FH LH
Tooling thread	Kelly	6 5/8 REG LH	6 5/8 REG LH	6 5/8 REG LH	6 5/8 REG LH	7 5/8 REG LH	6 5/8 REG LH	6 5/8 REG LH
Dimension (L×W×H) (mm)		2291× 638× 648	2267× 781× 660	2169× 638× 648	2980× 1060× 860	3034× 1096× 1110	2291× 638× 648	620× 660× 2099
Weight(kg)		777	1750	1500	2500	3060	777	625
