2014 Best Choice!!! Full recycling cable cutting and stripping machine

Specifications

cable cutting and stripping machine
1.Lifetime long
2.Reasonable price
3.Manufacture
4.Factory

Household/home use/domestic of cable cutting and stripping machine



Our main purpose :

We Provide complete service equipment installation, testing ,maintenance and staff Training,we can provide you the technical services for life and provide the best service to you . Help our clients gain profit in quicklly. We will provide the most environmentfriendly and safe products with high quality at most favorable price for the customer with perfect after service.

 Introduction of cable cutting and stripping machine :

 My company developed into a complete production line of Model TMJ-600 cable cutting and stripping machine (mainly recycling car line,communication cable,miscellaneous line),the device structure is novel,unique,compact,small power consumption,stable performance,one feeding,it can complete with its single machine.

After the separation equipment to complete the cable broken in the process of copper

and plastic separation and recovery.Equipment production pattern,good dust removal

equipment,production is controlled by a control box.Successful development of the

machine solved the pollution caused by burning take copper.Not only improve the quality

of the recovery of copper effect,and has the advantages of recycled plastics.

 Working Principle of cable cutting and stripping machine : After the separation equipment to complete the cable broken in the process of copper and plastic separation and recovery.Equipment production pattern,good dust removal

equipment,production is controlled by a control box.Successful development of the

machine solved the pollution caused by burning take copper.Not only improve the quality

of the recovery of copper effect,and has the advantages of recycled plastics.

When directly put into the machine, used cable is cut into granules first, during this process, copper and

plastic is separated but mixed together, then the granules are sent to vibration device for separation,

through wind blow and vibration, the copper and plasticis are separated, then pure copper comes out from

one side and pure plastic comes out from the other side, we collect the separated pure copper and plastic

at last!

1)Materials are crushed in the crusher to have plastic skin and copper granules;

2)The crushed materials (mixture of copper and plastic) are conveyed to the separator by the conveyor, during which procedure the plastic granules (including fiber, rope, or tapes, etc. mixed in the wires) are cleaned by the dust cleaner.

3)The separator is consist of separating board, eccentric device, adjustable amplitude device,and speed adjustable motor, etc. It is used to separate plastic and copper.

4)All units are installed on the underbed to form a whole structure, easy for transportation. The machine is adjusted ready for production before shipment, and customer only need to connect it to the power supply.





:

  Working process of cable cutting and stripping machine :

1. Crushing process
Put waste copper wire into crusher to grind the wire into granular
2. Conveying and dust-collecting
After crushing, the mixture of copper and plastic will be conveyed to the separator, during which

procedure the plastic granules (including fiber, rope, or dust, etc. ) are cleaned by the dust cleaner.
3. Separating and collecting process
The vibrating separator consists of separating board, amplitude adjustable device, and speed

adjustable motor, etc.



The advantages of cable cutting and stripping machine :

 Suits wide range of Wire/cable:

 1.Computer wire, Automobile/car wire, Telephone wie, Communication wire&cable etc.

 2.Single core, Double core, Multi-core etc.

 3.We put the waste wire/cable directly in the machine! No matter twisted or tangled together!

· High efficiency: 99% recycling rate. It can recycle copper/aluminum and plastic at the same time!
· Energy saving: It consumes less energy compared with the same products!

· Environmental friendly: no air pollution! All the dust is collected.

· Easy operation: easy installation, devices are fixed on the bottom board, easy to move or transport!

 Main data of cable cutting and stripping machine :



Product Name	Copper Granulator
Model No.	TMJ-600
Application	Communication wire, telephone wire, copper wire, copper wire,electric wire, etc.
Suitable size	<20mm
Dimension	2380*2000*2800mm
Weight	2800kg
Power	31.48kw
Capacity	300-400kg/h
Features	1.Compact structure, beautiful appearance, reasonable layout, easy installation, high production efficiency 2. The intelligent operation is convenient and makes the equipment in stable operation at utmost. 3. Low speed, high torque and light noise. 4. The crusher, sorting equipment and dust-collecting devices are platforms combined type, which make the equipment easy to move and transport.





Why are you choose us as your partner :

1 provide the guarantee

2 we can provide the best packing as our clients requirement .

3 The quality have the best ensure , and the percent pass rate is 100%

4 There are kinds of transportations : sea transportation , air transportation , expressage and so on.

5 Factory production, the factory price, the spot goods supply.

 I will provide you best service in 24 hours!
