API Hydraulic Liner Hanger of Oilfield Tool

API Hydraulic Liner Hanger of Oilfield Tool thumbnail-1
API Hydraulic Liner Hanger of Oilfield Tool photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
SENWELL
Type:
Other, Liner hanger
Contact Supplier Request Quote Chat Now
Shaanxi Senwell Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
china port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name SENWELL
Type Other, Liner hanger
Machine Type Drilling Equipment
Certification API
Material Carbon Steel
Processing Type Forging
Use Well Drilling

Specifications

1. Hydraulic liner hanger
2. Scientific structure
3. Simple operation
4 .Convenient maintenance
5.Enough stock

Hydraulic Liner hanger



The Hydro-Hanger is a proven performer in hanging long, heavy liners.
It has made it's mark in demanding, ultra-deep wells ensure success in any well applications.



Features:

1. Alloy steel made to tools is high grade, so that the tools can have high mechanical strength and hang heavier lines.
2. The tool can be operated by hydraulic which make the tool used in wells of complex conditions.
3. The plug and seat which contain a reliable lock-ring is easily drilled out.
4. The core for sealing can be lifted out of the well followed (with) the setting tool.
5. The assembly for sealing which is made by many groups of sealed parts have function of both-way sealing and have effect of good sealing.
6. The hydro-hanger is fixed centralizer top and bottom which can hold the tool centered to put up setting speed as well as protect cylinder and slip.
7. Without seeking pressure-balance point, only with 10000 to 20000 pounds of drill pipe weight on the setting nut housing, 15 to 20 right-hand turns will release the setting tool from the liner.



Detail Specification:

Technical specifications and parameters for Hydraulic Liner Hanger

Casing Size

Tool

O.D. up

O.D. down

Weight

Part Number

O.D.

in

in

Lbs/ft

in

5 1/2

3 3/4

14.0 – 20.0

SS120X054036

4.665

7

4 1/2

26.0 – 32.0

SS120X070044

5.969

7

5

26.0 – 32.0

SS120X070050

5.969

7 5/8

5 1/2

29.7 – 39.0

SS120X075054

6.438

9 5/8

5 1/2

40.0 – 47.0

SS120X095054

8.469

8 5/8

6 5/8

40.0 – 44.0

SS120X085065

7.500

9 5/8

6 5/8

40.0 – 47.0

SS120X095065

8.469

9 5/8

7

40.0 – 47.0

SS120X095070

8.469

10 3/4

7 5/8

45.4 – 60.7

SS120X106075

9.438

11 3/4

8 5/8

60.1 – 71.0

SS120X116085

10.375

13 3/8

9 5/8

54.5 – 68.0

SS120X133095

12.125

13 3/8

10 3/4

54.5 – 68.0

SS120X133106

12.125

Note:
1. Standard material: N-80.Special material by order.
2. For API 8-round short, X=1;
   For API 8-round long, X=2;
   For API buttress, X=3.
