Specifications
1.With double plug or with single plug2.Be used as wellhead unit in all kinds of cementing operation
Casing Cement Head with double plug
The casing cement-head with double plugs (called as cement-head) is a common cementing tool used as wellhead unit in all kinds of cementing operation. Comparing to cement-head with single plug, it owns longer cement-head body, and upper rubber plug and lower rubber plug can be put in at same time.
The tool owns some advantages such as simple construction, easy operation, high pressure resistance, manifold in common use, flexible in connecting. Especially, the lever type indicator can shows whether rubber plug goes through double plugs cement-head to enter casing so that operator can determine easily.
Detail Specification:
Technical specifications and parameters for Casing Cement Head with Double Plug | ||||
Type |
ST35-140 |
ST135-*178 |
ST35-140 |
ST35-140 |
size(mm) |
139.7(5 1/2") |
177.8(7") |
244.5(9 5/8") |
339.7(13 3/8") |
Casing coupling thread |
5 1/2" LTC/BTC |
7" LTC/BTC |
9 5/8" LTC/BTC |
13 3/8" LTC/BTC |
Overall length(mm) |
1886 |
1972 |
1701 |
2210 |
Manifold interface |
2" union |
|||
I.D. of plug container(mm) |
125 |
160 |
225 |
320 |
Length of plug container(mm) |
450 |
460 |
560 |
560 |
Max. working pressure |
35Mpa |
35Mpa |
35Mpa |
20Mpa |
Casing Cement Head with Single Plug
The casing cement-head with single plug is special tools for pumping slurry and releasing plug.
Feature:
- Quick-latch adapter is used to provide easier, faster and safer thread connection with API STC/LTC cementing casing.
- Indicator shows plug releasing.
- Balance pipe is developed.
Detail Specification:
Technical specifications and parameters for Casing Cement Head with Single Plug | |||||||
Type |
DDS |
ZDS |
|||||
size(mm) |
139.7 |
177.8 |
244.5 |
339.7 |
73 |
88.9 |
127 |
Overall length(mm) |
1400 |
1450 |
1700 |
1700 |
910 |
1012 |
1125 |
Manifold interface |
2" union |
||||||
I.D. of plug container(mm) |
125 |
160 |
225 |
320 |
52 |
72 |
100 |
Length of plug container(mm) |
450 |
450 |
550 |
550 |
290 |
340 |
405 |
Max. working pressure |
70Mpa |
35Mpa |
35Mpa |
20Mpa |
70Mpa |
70Mpa |
35Mpa |
