Home > Products > Cementing Tools > Oilfield Cementing tools YFZ-A Hydraulic stage cementer for drilling operation
Oilfield Cementing tools YFZ-A Hydraulic stage cementer for drilling operation
- 10000 Piece / Pieces per Month
- China main port
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | China | Brand Name: | SENWELL | Model Number: | Hydraulic stage cementer |
Type: | Other, Cementing tools | Machine Type: | Other, Cementing tools | Certification: | API |
Material: | Other, Alloy steel or as customer's requirement | Use: | Well Drilling |
Product Description
Features:
1. The internal-closing structure and non-rotating closing sleeve design eliminate the possible damage to the closing sleeve when drilling out accessories.
2. The pressure-relief design eliminates fluid trapping and compression which might occur while opening and closing the side ports.
4. A pump-down opening plug instead of a free-fall opening plug can be used for a continuous two-stage cementing operation.
Detail Specification:
Technical specifications and parameters for YFZ-A Stage Cementer | |||||
Specification (in) | 13 3/8” | 10 3/4” | 9 5/8” | 7 5/8” | 7” |
Overall length (mm) | 1211 | 1211 | 1170 | 1140 | 1140 |
Max. O.D (mm) | 384 | 310 | 282.5 | 230 | 208 |
Min. I.D (mm) | 315 | 225 | 220.5 | 174.2 | 157 |
Opening Pressure (Mpa) | 7Mpa | ||||
Closing Pressure (Mpa) | 5 |
Advanced equipment and techniques
Long-term cooperative relationships with more than a hundred famous and large manufacturers in China
High quality products and the best services to meet the strict needs of our customers
The business philosophy of "people-oriented, customer first and reliability first"
Successfully exported to Europe, America, the Middle East, South Africa and Southeast Asia
Shaanxi Senwell Drilling Equipment Co., Ltd. (SENWELL) is a comprehensive corporation, of which the business scope is manufacture, trade and sale.
Our company is engaged in designing, researching & developing, testing and manufacturing oilfield equipment and providing relative services.
Our business covers drilling stem tools, fishing tools,c oring tools, downhole tools, oil mining equipment, drill equipment, well control systems and pipes.
We welcome new and old customers from all over the world to contact us for future business relationships and achieving mutual success! To benefit from our strong OEM/ODM capabilities and considerate services, contact us today. We believe you will be better with our support!
