AUC1 4P 25A with semko certificate Electrical Contactor types
- 60000 Piece / Pieces per Month
- Ningbo/Shanghai
- T/T D/P D/A
You May Like
-
AUC6 with good quality Installation Electrical 24V Contactor
-
AUC6 coil voltage 110V Electrical Modular 24V Contactor
-
AUC1 coil voltage 110V Electrical Magnetic single phase electrical Contactor
-
AUC6 coil voltage 110V Electrical Modular single phase electrical Contactor
-
AUC6 with good quality Installation Electrical types of Contactor
-
AUC6 coil voltage 110V Electrical Modular types of Contactor
Product Details
| Place of Origin | Zhejiang, China | Brand Name | AOELEC/OEM | |
| Model Number | AUC1 | Electricity Type | AC | |
| Number of Pole | 4 | Phase | 3 | |
| Main Circuit Rating Voltage | Other, 48V/110V/230V | Main Circuit Rating Current | Other, 20A/25A/32A/40A/63A |
Product Description
Function and Feature:
Contactor are electromechanically controled switches used to control single
or mult-phase(high) power loads while the control itself can be (very) low power
Technical Data:
Rated current(In):20,25,40,63A
Rated operational voltage(Ue):230/240VAC
Control voltage(Uc):24/48/110/230VAC
Number of module:1M,2M,3M
Rated frequency:50/60Hz
Utilization category:AC1,AC3,AC7a,AC7b,AC5b
Electrical endurance:150000cycles(AC1,AC7a,AC3,AC7b)
Mechnical endurance:1,000,000cycles
Rated insulation voltage(Ui):500VAC
Rated impulse withstand voltage(Uimp):4KV
Terminal:pillar type
Cable termination:16/25mm2
Torque of screw:1.2/2Nm
IP degree:IP 20
Standards:IEC/EN 61095,IEC/EN 60947-1
Catalog No. CTN Size:46.5x24x17.5CM
| Model | Description | QTY/Box | QTY/CTN |
| AUC1-63-24/40 | 63A 24V 4NO | 4 | 40 |
| AUC1-63-48/40 | 63A 48V 4NO | 4 | 40 |
| AUC1-63-110/40 | 63A 110V 4NO | 4 | 40 |
| AUC1-63-230/40 | 63A 230V 4NO | 4 | 40 |
| AUC1-63-24/04 | 63A 24V 4NC | 4 | 40 |
| AUC1-63-48/04 | 63A 48V 4NC | 4 | 40 |
| AUC1-63-110/04 | 63A 110V 4NC | 4 | 40 |
| AUC1-63-230/04 | 63A 230V 4NC | 4 | 40 |
| AUC1-63-24/22 | 63A 24V 2NO+2NC | 4 | 40 |
| AUC1-63-48/22 | 63A 48V 2NO+2NC | 4 | 40 |
| AUC1-63-110/22 | 63A 110V 2NO+2NC | 4 | 40 |
| AUC1-63-230/22 | 63A 230V 2NO+2NC | 4 | 40 |
Aoelec Electrical was established in 2003,with 50 office guys and 240 workers now.Our products are present in more than 30 different countries from Middle Ease to South American,from Europen to Australia,from Southeast Asia to North Africa.And our product have KEMA,TUV,SEMKO,CB and CE certificates.
