MCP-D32 12V 24V DC Contactor

Application:

MCP-D Series DC Operated AC Contactor is suitable for using in the circuit rated voltage up to 660V AC 50/60HZ, and in rated current 9-95A in AC-3/380V load circuits. For remote controlling circuit making, breaking and frequently starting AC motors. It can be also conbined with the auxiliary contact group, air delay, thermal relay devices etc. It has specialties of equable&reliable action,quick while working.

Technical Data:

 Rated operating current(A):32A, 400V, AC-3

                                                  21A, 600V, AC-3

                                                  50A, AC-1

Rated working voltage(Ue):400V AC,600V AC

Rated operational power at AC3:230V,7.5kw

                                                           400V,15kw

                                                           650V,18.5kw

Conventional thermal current(Ith):50A(Main contacts)

                                                             10A(coil)

Rated control voltage:24V,48V,110V,230V,400V

Electrical endurance:800000 times,AC3

                                      200000 times,AC4

Mechnical endurance:8000000 times

Protection degree:IP20

Number of pole:3P,4P

Number of auxiliary:1NO or 1NC,3P

                                     2NO+2NC or 4P,4P

Standards:IEC60947-4-1,EN60947-4-1

Catalog No.                                                                      CTN size:42x26x20CM
