BFY Thin Blade Slitter ( Manual Adjust)
Introduction:
1,Slitting machines adopt front-scoring- feeding, back double rubber roll leading paper, paperboard running steady.
2,Slitting part: adopt high quality tungsten steel blade, sharp and long work-life, slice tidier, non-pressing and non-burr.
3,Scoring part: adopt 5 points scoring, scoring distance in-phase adjust, blazonry and easy to bend the carton sheet.
4,Electric control lift-down and correct error, easy to operate, suit for different requirements.
5,Grinding part: adopt automatic and manual two kind’s pneumatic grinding type, it could be grinding when working, improve work efficiency.
6,Adopt China famous brand or imported electric element, dependable performance.
Characteristics:
(1) Manual feeding paperboard.
(2) The slitting paperboard side is tidy, straight, smooth and non-burr.
(3) Its blades can be sharped (grinding) by manual or by automatic, can sharpen (grinding) the blades when slitting paperboard, which will improve the working efficiency highly.
(4) Pre-pressed paper, feeding insures the stable paper transmit.
(5) The edge slitting knife thickness is 1mm.
(6) With special alloy knives, long life for using.
BYF Series Blade Slitter And Scorer Machine-Single Type | ||
Wyazs Name |
Unit |
Model |
Width of passing paper board |
mm |
1700,1900,2100,2400 |
Speed of passing paper board |
m/min |
80-180 |
Number of knives |
piece |
4increase or decrease available |
Number of track-pressing wheels |
pair |
6increase or decrease available |
Min,dividing width |
mm |
130 |
Min,track-pressing width |
mm |
60 |
Diameter of knife |
mm |
260 |
Thickness of knife |
mm |
1mm |
Motor power |
kw |
4 |
Size |
mm |
(2400.2600.2800.3100)*1120*1400 |
Weight |
kg |
1250.1550.1950.2500 |
