1.Usage
This Wedding Invitation Card/Envelope bag Creasing and Cutting Machine is a special equipment for creasing and cutting ordinary cardboard corrugated board plastic and leather (Such as Brands,Invitation letters,Paper File,Cartons,Bags,Mats,Namecars and so on) ,applicable to printing packaging decoration and plastic industries.Machine is characterized by compact structure,fine workship,big pressure,high precision and easy and reliable operation,etc.
2.Features
*Use high level material integral casting for high intensity machine body.
*Single plate electromagnetic clutch is sensitive and reliable safety
*Operational height is reasonable arranged.the opening angle of moving bed is optimum
*Electrical apparatus is designed in conformity with IEC standard safety system
*Single pressing,continuous pressing,adjustable delay pressing available
*Reliable performance of safety protection system
*Automatic oil pump matching.
3.Technical parameter:
Model |
Inner Chase Size |
Speed |
Max.Rule Length |
Motor Power |
Machine Weight |
Packing (overall) Dimensions |
PYQ401C |
750*520mm |
25 |
<15m |
2.2kw |
2000kg |
1650*1400*1500mm |
PYQ203C |
930*670mm |
23±3 |
<25m |
4kw |
3000kg |
1750*1900*1700mm |
Company info:
Jialong Packaging Machinery Co.,Ltd is a academician of Chinese Packaging Technic Association.Our company specializes in discovery, development and production of corrugated cardboard production line, automatic flexo ink printing slotting die cutting machine, semi-autoatic flexo ink printing slotting machine,auto rotary die cutting machine ,single facer corrugator machine, flute laminating machine, automatic carton folder gluer machine,carton stitching machine, slotting machine, thin blade slitter scorer machine, egg tray making machine, paper edge protector making machine, paper tube core making machine and other relevant packaging machinery.
Many years before, our company considers “Quality is first, Honesty is root” as our principal, to meet customers’ demand is our target. We can supply from machine design to after-sale all service with high quality and professional technique.
We would like to cooperate with friend from every countries sincerely, and we will work hard to create the future of package together
