Help CenterSOFA RECLINER MECHANISM
Related Products
Specifications
code : HX-4910Specification:
1. The ottoman adopts the design of wide heavy gauge links and built-in articulating
elevated mid-ottoman. Profile shape designed for safety and appearance without
pinch points. Articulating designs allows use of wider & higher mid-ottoman for
elimination of entrapment areas and for leg support.
2. The system adopts the geometrically balanced design to balance chair operation.
The user can choose any position from sitting to full reclining.
3. The system uses direct drive with double locks. The direct drive with double over-
center locks enables maximum synchronization of side positive locking of both
sides. Square drive tube connects to and controls both left and right sides.
Ottoman is locked closed on both sides.
4. Minimum stack-up design. The adoption of the flatter links and wider base
mounting points enables greater bending resistance and greater stability and
strength.It improves weight capacity and durability.The mechanism base width is
closer to seat width while maintaining sufficient clearance between links to
eliminate possibility of interference.
5. Flanged links for stabilizer tubes. Set up the maximum strength stability and is
side to side. It eliminates problems with flexing and breaking of tubes end at
bend. Flange is on heavy gauge link instead of the lighter gauge tube which can
flex and break.
6. Large diameter cross tubes are used instead of formed straps makes the system
obtaining the maximum strength, side to side stability and torque control. Unique
design of flattened tube end maximizes torsional strength unlike non-tubular cross
members which have no significant torsional strength.
7. The system uses the extended life rivet joints design. All rivet joints have either
acetal or bronze rivet bushing and acetal spacers to eliminate any steel to steel
contact. No metal to metal noises when links contact nylon stop pins.
8. Safety features. Footrest bracket is spring loaded at all four corners which allows
the footrest to pull away from the seat and arm stumps if something becomes
trapped upon closing. Hand wand can be easily and quickly removed when not in
use to prevent children from operating chairs. 7 second cycle time with
smooth operation. Transformer is movable to a safe place to eliminate safety
hazards of high voltage to the chair.
9. Interchangeable on wood frame design.The wood frames designed for the rocker
recliner, motorized lift are all interchangeable.
10.The back of the chair a dopts the KD sleeve design for easy packaging and
installation.
