Help CenterHX-4181-Z Mechanism
US$ 25 - 35
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
HENGXIN, HENGXIN
Model Number:
HX-4181-Z, HX-4181-Z
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI /NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
HENGXIN, HENGXIN
Model Number
HX-4181-Z, HX-4181-Z
Specifications
this recliner mechanism can rocker and swivel ,it is uesd in chair and sofa with legs.Features Specifications:Sell glider sofa mechanism
4181-Z Rocker W/Swivel Product Characteristics
1. The ottoman adopts the design of wide heavy gauge links and built-in articulating elevated mid-ottoman. Profile shape designed for safety and appearance without pinch points. Articulating designs allows use of wider & higher mid-ottoman for elimination of entrapment areas and for leg support.
2. The system adopts the geometrically balanced design to balance chair operation. It is consistent and easy for operation by any person. The occupant is weight is used to balance operation. Meanwhile it controls the sitting position and reclining position. Springs here are only used for locking and the initial start of the opening.
3. The customer has several options as to how to activate the mechanism. There are cable style, outside handle style and inside handle style. Easy operation. Customer can choose to use handle or lever activation to open the mechanism and the color of the handle or lever. Slight footrest pressure will allow closing the ottoman.
4. The system uses direct drive with double locks. The direct drive with double over-center locks enables maximum synchronization of side positive locking of both sides. Square drive tube connects to and controls both left and right sides. Ottoman is locked closed on both sides.
5. Four point stabilizer tube system is adopted. The double pair of glide stabilizer makes exceptional side to side stability Stabilizer tube on each glide link and on the extreme end of the mechanism
6. Four point blocking system. All four glide links blocked while the ottoman is open to eliminate unwanted motion while reclining and to eliminate rearward tipping problems.
7. The system uses ball bearing glide joints. Greased full race ball bearing glide joints enables the mechanism runs more smoothly and less friction and longer lift.
8. The system uses the extended life rivet joints design. All rivet joints have either acetal or bronze rivet bushing and acetal spacers to eliminate any steel to steel contact. No metal to metal noises when links contact nylon stop pins.
9. Interchangeable on wood frame design. The wood frames designed for the rocker recliner, motorized lift are all interchangeable.
10. The back of the chair adopts the KD sleeve design for easy packaging and installation.
1. The ottoman adopts the design of wide heavy gauge links and built-in articulating elevated mid-ottoman. Profile shape designed for safety and appearance without pinch points. Articulating designs allows use of wider & higher mid-ottoman for elimination of entrapment areas and for leg support.
2. The system adopts the geometrically balanced design to balance chair operation. It is consistent and easy for operation by any person. The occupant is weight is used to balance operation. Meanwhile it controls the sitting position and reclining position. Springs here are only used for locking and the initial start of the opening.
3. The customer has several options as to how to activate the mechanism. There are cable style, outside handle style and inside handle style. Easy operation. Customer can choose to use handle or lever activation to open the mechanism and the color of the handle or lever. Slight footrest pressure will allow closing the ottoman.
4. The system uses direct drive with double locks. The direct drive with double over-center locks enables maximum synchronization of side positive locking of both sides. Square drive tube connects to and controls both left and right sides. Ottoman is locked closed on both sides.
5. Four point stabilizer tube system is adopted. The double pair of glide stabilizer makes exceptional side to side stability Stabilizer tube on each glide link and on the extreme end of the mechanism
6. Four point blocking system. All four glide links blocked while the ottoman is open to eliminate unwanted motion while reclining and to eliminate rearward tipping problems.
7. The system uses ball bearing glide joints. Greased full race ball bearing glide joints enables the mechanism runs more smoothly and less friction and longer lift.
8. The system uses the extended life rivet joints design. All rivet joints have either acetal or bronze rivet bushing and acetal spacers to eliminate any steel to steel contact. No metal to metal noises when links contact nylon stop pins.
9. Interchangeable on wood frame design. The wood frames designed for the rocker recliner, motorized lift are all interchangeable.
10. The back of the chair adopts the KD sleeve design for easy packaging and installation.
