China top seller Semi-automatic flute laminater machine/High speed Automatic Flute laminator machine
- 6 Carton / Cartons per Month
- tianjin
- T/T
- Automatic Screw Counting Packing Machine
- Maquillagemembrane packing machine Gift packageseal and cut the packaging machine
- Bookbag packing machine Seal the heat-shrink packaging machine
- E-commerceseal, cut and paste single package machinery Cloud warehousebouch paste single charter
- Aluminum meal boxcover packaging equipment Bookseal the heat-shrink packaging machine
- Bookset of film packaging machine
Product Details
Condition: | New | Function: | Laminating | Application: | Other, Machinery & Hardware |
Packaging Type: | Film | Packaging Material: | Plastic | Automatic Grade: | Automatic |
Driven Type: | Electric | Voltage: | 380V | Power: | 12KW |
Place of Origin: | Hebei, China | Brand Name: | jialong | Model Number: | BZJ-1300 |
Dimension(L*W*H): | 1300x1100x1250 | Certification: | CE/ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
semi-automatic flute laminating machine
Parts Introductions:
Electrical Control Unit
|
Transmission Unit
|
Glue and Compress stacking Unit |
All the electrical power adopted the world renowned brands, steady and durable, frequency speed governing, lower noise and energy conservation. | It can achieve the location and correction of the cartons at the high speed of transmitting. | The glue-wheel made of stainless steel and anilox roller glues, it can reduce the quantity of the glue and improve the intensity of the cartons. Deft design keep the carton perfect. |
Top Feeding Unit | Bottom Feeding Unit | Locating Unit |
The motor blade adopted the world's most advanced similar structure to the cutting machine .It is easy to adjust ,transmitting smoothly with different types of papers including: double papers Alice papers and the papers of laminating varnishing etc. | This unit adopted the unique electrical transmission structure, ensure the high speed of sheet conveying and accuracy and not deflect. The transmitting belt has strong adaptability of the Alice of corrugated paper. |
Make track for the fixed position, and it can solve the problem of deformation caused by the impact of GPS positioning, making the speed much more rapidly. |
Fnction description:
1. Using suction feeding automatic of bottom sheet, according to the main machine operating speed, continuous automatic tracking
2. The humanized design that manually feeding from the front makes delivery more easier and efficient.
3. Entire new concept, front gauge registration, position high accuracy, bottom sheet never exceeds the top sheet.
4. The automatic replenishment system of glue can be added automatically during glue losses, and recycling with the glue to avoid loss of waste;
5. The scientific design of the metering roller speed to ensure the glue evenly on the same time, to avoid rejection of glue at high speed.
6. Floating removable press, to ensure that laminated paper will not be crushed, and also keep the cardboard smooth and straight; unilateral adjustment by way of adjustment worm roll lamination pressure for quick
7 Control of water tank cleaning cycle using an independent method, clean, hard rubber product;
8. Suitable for color top sheet 120-500g cardboard and A/B/C/D/E/F corrugated paper laminating;
Main Technical Parameter:
Model | 1300 | 1450 | 1600 |
Maximum size(W*L) | 1300*1100mm | 1450*1100mm | 1600*1400mm |
Minimum size(W*L) | 350*350 | 350*350mm | 450*450mm |
Laminate precision | ≤±1.5mm | ≤±1.5mm | ≤±1.5mm |
Speed | 6000 sheets / h | 6000 sheets / h | 6000 sheets / h |
Total power | 4.5kw | 4.5kw | 4.5kw |
Machine size | 8.8*1.95*1.5m | 8.8*2.2*1.5m | 8.8*2.5*1.5m |
Total weight | 3T | 3.2T | 3.5T |
