All You Want BZJ-1300 High Speed Automatic Flute Laminator Machine

All You Want BZJ-1300 High Speed Automatic Flute Laminator Machine photo-1
All You Want BZJ-1300 High Speed Automatic Flute Laminator Machine photo-2
All You Want BZJ-1300 High Speed Automatic Flute Laminator Machine photo-3
All You Want BZJ-1300 High Speed Automatic Flute Laminator Machine photo-4
US$ 30,000 - 30,000 MOQ: 1 Carton
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Film
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Machinery & Hardware
Packaging Type Film
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 12kw
Place of Origin Hebei, China
Brand Name JIALONG
Model Number JL-9000
Dimension(L*W*H) 9000x2500x2000
Weight 2500kg
Certification CE ISO9001
After-sales Service Provided Engineers available to service machinery overseas

All You Want BZJ-1300 High speed Automatic Flute laminator machine

All You Want BZJ-1300 High speed Automatic Flute laminator machine

Function description:

1.  Top sheet feeding machanism: equipped with high speed auto dedicaed feeder, both paper lifting and feeding nozzle can freely adjust angle to the paper, to ensure that whether thick or thin paper can be delivered rapidly an smoothly.



2.  Prepare the paper-pile in advance, it can reduce dowetime and make the production more efficent.



3.  Cooperate with the adjustable bottom paper conveying system  and imported  electromagnetic valve to guarantee the corrugated sheets feeding more smooth and stable.



4.  The automatic replenishment system of glue, and recycling with the glue to avoid loss of waste.



5.  Front lay is  automatic calibrated by Electric eye, Computer and Servo motor. The position of cardboard is detected by Electric eye, then the Computer operation, the Servo motor rectify automaticly, insure the precision of laminating.



6. According to the size of cardboard, revise the feeding speed of cardboard automaticly.



7.  Machine uses touch-sceen/PLC control system, the circuit system is stabe, and can automatically dispaly the failure alarm.



8. Using imported belt, maintaince free. Rollers are in balance of static and dynamic, the rollers cooperate with the imported bearings that make the equipments more stable, and can guarantee procutes quality.



9.Suitable for color top sheet 150-700g and A/B/E corrugated paper laminating;


10.Color top sheet 150-700g and grey cardboard paper laminating.



Main Technical Parameter:




Model

Max. Sheet size

Min. Sheet size

Total power

Speed

Weight

Measurement

GTM-1300

1300*1200

450*450

15kw

10000sheet/h

6500kg

11000*2000*2500

GTM-1450

1450*1200

450*450

15kw

10000sheet/h

7500kg

11000*2150*2500



   laminator machine

Machine details:

 All You Want BZJ-1300 High speed Automatic Flute laminator machineAll You Want BZJ-1300 High speed Automatic Flute laminator machine





   laminator machine





   laminator machine



 All You Want BZJ-1300 High speed Automatic Flute laminator machine





laminator  machine



 All You Want BZJ-1300 High speed Automatic Flute laminator machine





   laminator machine



 All You Want BZJ-1300 High speed Automatic Flute laminator machine



All You Want BZJ-1300 High speed Automatic Flute laminator machine
