LC PWI label printer weighing indicator
Standard Function:
Can store weighing data ,can store/check/delete
High precision A/D conversion with readability 1/30000
AC/DC power supply, with inside rechargeable 6V/4AH battery
Able to setup zero-tracking range
Able to setup print function
Weighing data save/check/delete
Standard RS232 communication interface with selectable baud rate and communication method
Technical Parameter:
A/D conversion method: ∑–
A/D conversion speed: 8 times/sec.
Max. A/D conversion bits: 20
Input signal range: -20mV~20mV
Input sensitivity: ≥ 0.02 μ V/e
Load cell excitation: DC 5V: 1 ≤ 150mA
Max. connection number of load cell:8 at 350 ohm
Load cell connection mode: 4 wire, auto compensation for long distance ≤ 10 meters
Verified counts: 30000
Display: 6 bits LCD, 8 status indications
Power supply: AC 230V, 50~60Hz; DC inside rechargeable 6V/4AH battery
Paper size:wide 57-58mm,diamter 38mm
Model |
LC PWI |
LC PWI |
Display |
6 bits LCD |
6 bits LED |
Capacity |
6-800000kg |
6-800000kg |
Verified counts |
30000 |
30000 |
A/D conversion method |
∑— |
∑— |
A/D conversion speed |
8 times/sec |
8 times/sec |
Max. A/D conversion bits |
20 |
20 |
Input signal range |
-20mV~20mV |
-20mV~20mV |
Input sensitivity |
≥0.02 μ V/e |
|
Load cell excitation |
DC 5V: 1 ≤150mA |
DC 5V: 1 ≤ 150mA |
Max. connection number of load cell |
8 at 350 ohm |
|
Load cell connection mode |
4 wire, auto compensation for long distance ≤ 10 meters |
|
Temperature |
0°C to +40°C / +32°F to +104°F |
|
Power supply |
AC 12V/500mA ; DC inside rechargeable 6V/4AH battery |
|
Calibration |
Manual calibration |
|
Calibration weight |
1%-100% Cap. |
1%-100% Cap. |
Appearance |
ABS |
|
Scale size(w x d x h) |
260x156x68mm |
|
Net weight |
1.35kg |
|
