Home > Products > Wall Washer > 24W High Power Linear LED Wall Washer Light with IP65 Waterproof
24W High Power Linear LED Wall Washer Light with IP65 Waterproof
- 500 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
Product Details
LED Light Source: | Epistars | Warranty(Year): | 2 | Input Voltage(V): | 24 |
Lamp Power(W): | 38 | Lamp Luminous Flux(lm): | 2600 | Lamp Luminous Efficiency(lm/w): | 80 |
Color Temperature(CCT): | Other, RGB | Working Temperature(℃): | -10, 50 | Working Lifetime(Hour): | 50000 |
Lamp Body Material: | Aluminum | IP Rating: | IP65 | Certification: | CE, EMC, FCC, LVD |
Brand Name: | Heguang | Model Number: | HG-WW-36*1W |
Product Description
Specifications
LED Wall WasherBody: aluminum+tempered glass cover
DX512 control methods
RGB control synchronization
Constant driver
24W High Power Linear LED Wall Washer Light with IP65 Waterproof
Led wall washer specification
Specification | Parameter | |
Model No. | HG-WW-36X1W | |
LED Qty | 36pcs High power LED | |
Input Voltage | DC 24V | |
Input Frequence | 50/60 Hz | |
Power | 38±1.5 W | |
Luminous flux | White: 2200-2600lm±10% | |
Working temperature | -10-60℃ | |
Color temperature | p.w.-6000~7000k w.w.:3000-3500k c.w.-8000~12000k | |
Wave Length | R:620-630 G:515-525 B:460-470K/nm | |
Dimension | 1028×90×128mm | |
Lighting Distance | 8-20m | |
Constant driver | yes | |
IP rate(w/housing) | IP65 | |
Constant driver & overcurrent protection | yes | |
Packing | 4 pcs in 1090×270×290mm ctn N.G:16.8 kgs |
RGB wall washer features
1. LED wall washer series is linear type design,for symmetrical lighting.Fluent RGB patterns can be lighted up high buildings or as a decoration for wall both indoor and outdoor.
2. The main body is thickened type aluminum with temoered glass cover.Sealed by silicone ring,then fixed by screws. Surface is anodic oxidation finish (silvery grey) which make the light can work in outdoor (rainy and multiple weather..And it is easy to install.
3. High power LED as light source,with chip from Epistar,Epileds and Bridelux
4. Constant driver to make sure LED light working stably,with LED display and buttons to control RGB color
5.Voltage:DC 24V, Frequency: 50/60HZ
6. Color: RGB,or single color – white, red, green, blue, yellow
7.Beam angle: 15°/30°/45°/60°
8. Life span 50000 hours
9. Over current protection
Outdoor wall washer application: Tower Bridge High building Garden
Led wall washer detailes images
TOP VIEW | FRONT VIEW |
LIGHTING VIEW | BACK VIEW |
CONTROL BOARD | DIMENSION DIAGRAM |
Service
1. Your inquiry related to production or price will be reply in 24 hours
2. After-sales tracking service for each of client
3. Well trained and experience staff to answer all you inquiries
4. 2 years warranty of our product, if you have any problem in 2 years, we will sent the new items replace damaged items
5. Special discount & protection of sales areas and you private information
Quality
1.To open LED pool lights mold by ourselves, so we can control quality of product
2. We have strict quality control process, all of products 100% pass QC inspection
3. Each will be aging more than 8 hours before delivery
4. All components are hight quality and long life time
5. warranty 24 months
6. CE, FCC,ROHS ,IP 68 waterproof certificates
