Built-in Battery Video Signal FM Transmitter

Internal Battery PersonalWireless FM Video Transmitter

SG-BX1000

SG-BX1000 is designed on the basis of SG-8000B, and is a new type video transmitter characterized by small size, portable, and internal batteries. Adopt Motorola integrated power amplifier with power of 10W, transmits 500-800 meters with obstacles(use 3dBi antennas), 800-1500 meters in a clear line. The work time of every charge is 4-6H. It has good penetrability, especially suitable for single soldier for field work, covert investigations, as well as special tasks for live events.

Features:

1) Small size, compactness, light and safety;

2) NLOS distance up to 500~800m;

3) FM modulation, good performance for field task or military training.

Specifications:

Appearance:

Receiver:

Transmitter:

How to operate the receiver:

1) Please use DC12V 200mA power supply;

2) There is a digital display on the receiver, it can display the frequency on this screen.

3) You can change the frequency and channel to receive ideal image by press on the “CONTROL” button;

4) Make sure the transmitter and receiver are set to the same channel.

Q & A

Q1: There is no video signal.

A: Bad connection. Please check all the connector plugs and jack. Please make sure that power switch cable and the antenna connected well to avoid unnecessary problems.

Q2: It is unstability vedio screen or looks blurred.

A: Please move the antenna slowly, and fix when it has ideal effect. If this don’t work at all, please trying to raise the receive antenna still higher.

Q3: How do I test a newly purchased wireless video tranceiver system?

A: STEP1: Please install the antenna to the transmitter, then connect the camera to it correctly. STEP2: Please connect the receiver to the TV monitor, and make sure that the camera and the monitor are properly. STEP3: Turn on the power switch on the transmitter, adjust the “CONTROL” button on the receiver to get normally image effect.
