Cotton Yarn Spinning Machine/Ring spinning frames
YISUN Ring Spinning frame series are made from the leading design proposal,advanced
manufacturing methods and perfect special parts and components. They ensure high quality
yarn spring. The machine features convenient operation and easy to management due to its high
automation. It is suitable for spinning of cotton and synthetic fibres or their blends to produce
weaving or knitting yarns.
The machine is suitable to the processing of cotton,synthetic fibers or their blends.
YX88-16 Technical Data and Specifications:
Spindle gauge | 70mm |
Lifting | 205 180 155 mm |
Ring Diameter | Φ45,Φ42,Φ38mm |
Number of Spindle | 384,396,408,420,432,444,456,468,480,492,504,516 |
Yarn count | 97.2---4.9tex (6--12Ne) |
Twist | 300--1600(T/m) |
Draft Ratio | 10-50 |
Spindle speed | 15000-22000 rpm |
Spindle drive | Single tension pulley,Z or S twist optional |
Spindle wharve diameter | Φ22,Φ24,Φ20.5mm |
Creel | One tier hanger, Four or six rows optional |
Main Motor(380v50Hz) | 15/7KW 17/9KW 18.5/11KW 22/11KW (380v) |
Suction Motor (380v 59 Hz) | 1.5KW(for No.of spindles below4444) 2.2KW (for No.of spindles above 456) |
Lift Motor | 370W |
Distance between Spindle of left and right side | 700 mm |
Headstock dimensions Endstock Dimensions | Width: 640mm, length:680mm, height:1700mm Width:640mm, length:1300mm,height: 1768mm |
Total height of the machine | 2300mm |
Total length of the machine | L=2380+(N/2-1)70mm L:length N:where means the number of spindles |
Qingdao Yisun Machinery CO.LTD., established in 2000, lies in Wangtai Town, Qingdao--- the most important production base of textile machinery. Our company possesses a big workshop covering an area of 12000 square meters. We develop more than 100 sets of professional production equipment, and more than 200 staff, among which there are more than 30 technical workers.
1,How to contact you?
You could contact us via skype, wechat, QQ, email or call us directly.
2,Are you factory or trading company?
We are factory with foreign trading property. That is to say,we produce machines and we export to customers by ourself.
3,How many countries have your products been exported to?
Until now our machines have been already exported to more than 100 countries.Welcome to visit us.
4,Which payment term is accepted?
30% in advanced payment by T.T and 70% paid before shipment by T.T.
Welcome for your inspection for the machines before shipment.
5,Can you make speicial voltage of the machines?
yes,usually the machines are made with 380v,50hz,3 phases or 220v,50hz,single phases.If you need special, please inform us and we customize.
