12m Fiberglass Triangle Telescopic Hot Stick Quality Choice
Specifications
12m Fiberglass Triangular hot stickescopic hot stick/extension pole
2.fiberglass/light epoxy resin
3. high voltage
Fiberglass Triangular telescopic hot sticks(3m-15m)
This Fiberglass Triangular telescopic hot stick is suitable for high voltage switch out operating. They are produced from epoxy resin, super light, high voltage, high strength. The length and sections can be made depending on your request.
The Telescopic Hot Sticks come equipped with a universal spline end and hot stick probe. In addition, the Telescopic Hot Sticks come with the tip lock operational feature standard. The operator can simply lock the end section into second to last section if necessary to obtain maximum flexural/tensile strength from the extended stick to open/close stubborn equipment. Remember when utilizing the tip lock feature the operator will lose approximately 5 foot of extended reach.
The Telescopic Hot Stick is the newest generation of fiberglass hotstick to enter the electrical market. The stick has been engineered, so additional fiberglass has been added where the highest strength is required and removed where it is not required. The result is a telescopic stick able to withstand the rigors of line operations and still offer the utmost in lightweight for portablility. The outside surface texture provides a positive gripping surface even in wet conditions. All operating buttons are CNC machined from very high strength and water resistant engineered solid polymer rod to provide maximum mechanical strength.
Withstand Voltage | Total length | Section | Weight |
10KV | 3m/4m | 3sections | 1.93kg/2.57kg |
35KV | 4.5m | 3sections | 2.9kg |
110KV | 5m | 3sections | 3.22kg |
220KV | 6m | 4sections | 3.86kg |
500KV | 8m | 4sections | 5.14kg |
