Specifications
t5 led light 1160mmwell-known brand LED chip luminous source,
high efficiency, long rated life
Seamless natural white 1160mm t5 led light
Integrated structure, making installation easier
2-color plastic shell, light, simple, built-in aluminum, good heat dissipation.
With a double-ended serial interface, supports up to 20 serial connecting, saving man power
Hao Ming-T5 bracket lamp
| Chip type | Working environment | Installation | Protection grade | Rated life | Input voltage | Color | Material | certification | ||||
| 2835 | -20 ℃ ~ +40 ℃
| Wall mounting | IP20 | 30000h | 220~240V/50~60Hz | White | PC | CCC |
| |||
Specifications
MODEL# | Dimensions | Size A*B*C | CCT | Power | The number of chips | Power of the whole lamp | Efficacy | CRI | Power efficiency | Electrical protection | Package quantity |
BTMC7096A3U | 1.2m | 1170*35*24mm
| WW / NW / CW
| 14W
| 96 | 14W
| ≥ 95Lm / W
| ≥ 80 | 92% | Class Ⅱ
| 40 PCS / Box |
BTMC7072A3U | 0.9m | 885*35*24mm
| WW / NW / CW
| 10W | 72 | 10W | ≥ 95Lm / W
| ≥80 | 92% | Class Ⅱ
| 40 PCS / Box |
BTMC7051A3U | 0.6m | 585*35*24mm
| WW / NW / CW
| 7W | 51 | 7W | ≥ 95Lm / W
| ≥80 | 90% | Class Ⅱ
| 40 PCS / Box |
BTMC7024A3U | 0.3m | 317*35*24mm | WW / NW / CW
| 3.5W | 24 | 3.5W | ≥ 95Lm / W
| ≥ 80 | 86% | Class Ⅱ
| 40 PCS / Box |
IV. Production capability
TIWIN owns automated production lines, production equipment and instruments, including 9 SMT production lines, 65 sets equipments, such as: automatic wave soldering, reflow soldering, automatic braiding, automatic optical spectral machines and other production equipments..
We own 41 assembly lines, with more than 185 sets automatic printing machine, glue machine, burn-in machine and waterproof IP67/68/65 test equipments.
