Help Center12W LED Square Module
Negotiable
MOQ: 1 Carton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
3014
Input Voltage(V):
220-240V
Lamp Power(W):
12
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TIWIN 3W LED Square Module ,square PannelNegotiableMOQ: 30 Pieces -
TIWIN 7W LED Square Module for BuildingNegotiableMOQ: 30 Pieces
-
TIWIN 12W LED Panel Square ModuleNegotiableMOQ: 30 Pieces
-
TIWIN 3w Square Smd Led ModuleNegotiableMOQ: 10 Pieces
-
TIWIN 7w Square Led Module LightNegotiableMOQ: 10 Pieces
LED Light Source
3014
Input Voltage(V)
220-240V
Lamp Power(W)
12
Lamp Luminous Flux(lm)
1000
Lamp Luminous Efficiency(lm/w)
80
Color Temperature(CCT)
Cool White
Working Temperature(℃)
-20, 40
Working Lifetime(Hour)
25000
Lamp Body Material
Other
Certification
CCC
Place of Origin
Jiangsu, China
Brand Name
TIWIN
Model Number
GRMA1201CCU
Specifications
Applications: public spaces, offices, subway stations, shopping malls and other indoor lighting places2-year warranty
Performance Characteristics
GRMA series |
Working environment |
chip type |
Installation |
Protection grade |
Rated life |
Color |
Beam angle |
Material |
Input voltage |
|
-20~40 |
3014 |
embedded |
IP 20 |
25000h |
Aluminum color |
110°
|
aluminum |
220-240V/50-60Hz |
Specifications
model |
Dimension |
Power of lamp |
Luminous flux |
Lamp beads
|
Color temperature
|
CRI |
Luminous efficiency |
Package number |
GRMA1201CCU |
185×185×45mm |
12W |
1000Lm |
120
|
6000K
|
>=70 |
85 |
20PCS/box |
GRMA0701CCU |
135×135×45mm |
7W |
600Lm |
72
|
6000K
|
>=70 |
80 |
20PCS/box |
GRMA0301CCU |
90×90×45mm |
4W |
300Lm |
36 |
6000K
|
>=70 |
70 |
20PCS/box |
