US$ 18 - 23
MOQ: 300 Pieces
Key Specifications
Get Latest Price
LED Light Source:
3030
Warranty(Years):
5
Input Voltage(V):
90V~277VAC
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Design Down Light Led With Great Price TIWIN 3W 5w 7w 9w 13w 16W Cheap Led Down LightNegotiableMOQ: 50 Pieces -
Top Quality Recessed Downlight With Low Price TIWIN 3W 5w 7w 9w 13w 16W Cheap Led Down LightNegotiableMOQ: 50 Pieces
-
High Power Recessed Downlight With Great Price TIWIN 3W 5w 7w 9w 13w 16W Cheap Led Down LightNegotiableMOQ: 50 Pieces
-
Professional Led Downlight 12w Made in China TIWIN 3W 5w 7w 9w 13w 16W Cheap Led Down LightNegotiableMOQ: 50 Pieces
-
New Arrival Recessed Downlight With Low Price TIWIN 3W 5w 7w 9w 13w 16W Cheap Led Down LightNegotiableMOQ: 50 Pieces
LED Light Source
3030
Warranty(Years)
5
Input Voltage(V)
90V~277VAC
Lamp Power(W)
15
Lamp Luminous Flux(lm)
1510
Lamp Luminous Efficiency(lm/w)
100
Color Temperature(CCT)
Warm White
Working Temperature(℃)
-25, 65
Working Lifetime(Hour)
40000
Lamp Body Material
ABS
IP Rating
IP44
Certification
CCC, CE, CQC, EMC, GS, LVD, REACH
Model Number
TD-15
Place of Origin
Jiangsu, China
Brand Name
TIWIN
Specifications
100LM/W Highest efficiency and energy-saving level in the worldRA>83
Product Description
Name | XINYUE Down Light |
Model | DL6C1016A8U |
Code | DL6C1016A8U -Y530WH5N101 |
Standard | GB7000 |
Certificate | CCC |
Size | Φ175*101mm ,Cut-Out Φ150mm |
Material | Die-Casting Aluminum (ADC12) |
Weight(Kg) | 0.53Kg |
Housing Color | White |
IP | IP20 |
Adjustment | / |
Install Method | Embedded |
Dimming | No Dimming |
Rated lifetime | ≥25000h |
Work Environment | -25~35°C |
LED Brand | Lightning optoelectronic |
LED Type | 3030 |
LED QTY. | 16pcs |
Flux | 1510lm |
Beam Angle | 80 |
CCT | 3000k |
CRI | 83 |
Driver Brand | TIWIN |
Power | 14.67W |
Input | AC220V~240V,50/60Hz |
output | / |
current | 140mA |
Efficiency | 94% |
PF | 0.91 |
Electrical protection grade | CLASS I |
Control Method | / |
Driver IP | / |
Driver Location | Integration |
Inter box | 217*213*125 (mm) |
Carton | 652*446*481 (mm) |
Weight(Kg) | 16kg |
Accessory | Installation instructions |
Packing Way | 20 PCS/Carton |
