Specifications
TIWIN Ji Yao 16w LED DownlightBeautiful and delicate, slim styling, high CRI, soft and uniform light
TIWIN Ji Yao Residential indoor 16w LED Downlight
Item | Working environment | Chip type | Beam angle
| Input voltage | Installation | Protection grade
| Rated life | Color |
Ji Yao LED Downlight
| -10℃~ 40℃
| SMD | 90°
| 220~240V/ 50~60Hz
| Embedded | IP40 | 40000H | White |
Specifications
MODEL# | Size | Openings size | CRI | CCT | Power | Luminous flux
| Electrical protection
| Power factor | Package quantity
|
DL3D0501A8U | φ105*65mm
| φ95mm | ≥80 | 3000~6000K | 5W | 360LM | CLASS Ⅱ
| >0.8 | 75PCS/box |
DL4D0701A8U | φ135*72mm
| φ120mm
| ≥80 | 3000~6000K | 7W | 500LM | CLASS Ⅱ
| >0.8 | 60PCS/box |
DL4D0901A8U | φ135*72mm | φ120mm | ≥80 | 3000~6000K | 9W | 700LM | CLASS Ⅱ
| >0.8 | 60 PCS/box |
DL6D1301A8U | φ190*80mm | φ175mm | ≥80 | 3000~6000K | 13W | 1000LM | CLASS Ⅱ
| >0.8 | 24PCS/box |
DL6D1601A8U | φ190*80mm | φ175mm | ≥80 | 3000~6000K | 16W | 1250LM | CLASS Ⅱ
| >0.8 | 24PCS/box |
I. Introduction
II. Sample rooms
IV. Production
V. Warehouse
Send Inquiry to This Supplier
