Home > Products > Wire to Wire Connectors > 1.58mm Pitch Male Female Wiring Harness Connectors
1.58mm Pitch Male Female Wiring Harness Connectors
US$ 0.01 - 1
/ Piece
1000 Pieces(Min. Order)
- HK
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | SWB | |
| Model Number | 7725 | Type | Adapter | |
| Application | PCB | Gender | Female |
Product Description
1.58mm pitch male female wiring harness connectors
Product Highlights
- Category: Wire to Wire connectors
- Current: 15A
- Pitch: 1.58mm
- Circuits: 2~15
- Voltage: 250V AC/DC
- Temperature range: -25 C~+85 C
- Contact resistance: 10 oumu max
- Insulation resistance: 100 oumu Min
- Withstanding voltage: 1500V AC/minutes
- Wire range: AWG#14-20
Primary Competitive Advantages:
- Brand-name Parts
- Country of Origin
- Experienced Staff
- Green Product
- Guarantee/Warranty
- Competitive Price
- High Quality
- Prompt Delivery
- Cetification: ISO9001/SGS/UL/RoHS/Reach
- Best Re-Sale and After-Sale Service
- Small Orders Accepted
- Free Samples
