Specifications
orange PP/PE shower waterproofing materialEasy and fast installation
ANSI108.10 standard
0.6mm thickness
Light-weight
Eco friedly ANSI108.10 Shower Liner with orange colors
Function:
HUIYUAN is a pliable, sheet-applied, bonded waterproof membrane and vapor retarder with limited crack-bridging capabilities. It is made of soft polyethylene, which is covered on both sides with a special fleece webbing to anchor the membrane in the thin-set mortar. HUIYUAN was developed as a waterproofing membrane to be used in conjunction with ceramic and stone tile coverings. Tiles can be installed directly on HUIYUAN using the thin-bed method. Other trowel-applied covering materials, such as plaster, can also be used.
HUIYUAN is a bonded waterproofing membrane and vapor retarder with very low water vapor permeance for use in continuous use steam rooms and similar applications.
Various HUIYUAN waterproofing accessories are available. Use HUIYUAN-BAND, in widths of 5" (12.5 cm), 7-1/4" (18.5 cm), or 10" (25 cm) to seal butt joints or corner joints. HUIYUAN-FLEX, in 5" (12.5 cm) or 10" (25 cm) widths, is used to seal expansion joints or flexible edge joints.
HUIYUAN are preformed, seamless corners for waterproofing 135(deg) angles between triangular shower benches and walls or tops of curbs in neo-angle shower applications. HUIYUAN are preformed, seamless corners made of HUIYUAN for waterproofing floor/wall/shower base connections in curbless shower applications where the HUIYUAN-LINE linear drain is installed adjacent to the wall.
Product Features:
l Light-weight and Eco-friendly;
l Pliable material and compatible with various shapes of base;
l Easy and fast installation, saving installing time and labor cost;
l Excellent moisture barrier performance.
Applicable Scope:
l Moisture barrier liners in showers, steam rooms, swimming pool surroundings;
l Interior application of ceramic and stone tiles;
l Other wet areas like shopping centers, food courts, commercial kitchens, etc.
Product Specification:
Description |
PP/PE Shower Liner |
Material |
polyethylene(PE) film; polypropylene(PP) nonwoven |
Roll Size |
1mx100m |
Weight |
300g/sqm |
Thickness |
03mm~0.5mm |
Packing |
100sqm/roll wrapped in plastic film |
Colors |
Purple or customized |
Technical Parameter:
Waterproof Membrane for Thin-set Ceramic Tile and Dimension Stone Installation complying with ANSI108.10 of USA.
Property |
Test method |
Requirement |
Performance |
Fungus and micro-organism resistance |
|
The membrane shall not support mold growth |
Pass |
Seam strength |
ASTM D751 |
16 lb/2 in width |
36 lb/2 in width |
Breaking strength |
ASTM D751 |
170 psi |
1084 psi |
Dimensional stability |
ASTM D1204 |
0.7% maximum length change |
Pass |
Waterproofness |
ASTM D4068 |
No moisture penetration |
Pass |
7-day shear strength |
ASTM C482 |
50 psi |
87 psi |
7-day water immersion shear strength |
ASTM C482 |
50 psi |
77 psi |
4-week shear strength |
ASTM C482 |
50 psi |
96 psi |
12-week shear strength |
ASTM C482 |
50 psi |
90 psi |
100-day water immersion shear strength |
ASTM C482 |
50 psi |
120 psi |
Water vapor permeance |
ASTM E96 |
|
0.75 perms |
