Shower Room Construction Waterproof Material

Specifications

Shower Room Construction Waterproof Material
Easy and fast installation
ANSI108.10 standard
0.4mm thickness
Light-weight and



Shower Room Construction Waterproof Material

Product Introduction:

Bairui Shower Liner is especially designed for waterproof in shower rooms and other wet area. This product is a composite sheet membrane made of soft polyethylene(PE) with nonwoven polypropylene(PP) fabric laminated on both sides to enable the membrane fixed firmly onto mortar.

Bairui Shower Liner is flexible and conforms to various contours of the wood framing, bending upward at the walls and folding into corners. It can be applied directly with thin-set mortar, ceramic and stone tile, provides waterproofing and crack isolation/joint bridging for thin-set installations of ceramic and stone tile. It has been an ideal membrane to protect the substrate from moisture penetration.



Product Features:

l  Light-weight and Eco-friendly;

l  Pliable material and compatible with various shapes of base;

l  Easy and fast installation, saving installing time and labor cost;

l  Excellent moisture barrier performance.



Applicable Scope:

l  Moisture barrier liners in showers, steam rooms, swimming pool surroundings;

l  Interior application of ceramic and stone tiles;

l  Other wet areas like shopping centers, food courts, commercial kitchens, etc.







Product Specification:

Description	PP/PE Shower Liner
Material	polyethylene(PE) film; polypropylene(PP)   nonwoven
Roll Size	1mx100m
Weight	300g/sqm
Thickness	03mm~0.5mm
Packing	100sqm/roll wrapped in plastic film
Colors	Purple or customized



Technical Parameter:

Waterproof Membrane for Thin-set Ceramic Tile and Dimension Stone Installation complying with ANSI108.10 of USA.

Property	Test method	Requirement	Performance
Fungus and micro-organism resistance		The membrane shall not support mold growth	Pass
Seam strength	ASTM D751	16 lb/2 in width	36 lb/2 in width
Breaking strength	ASTM D751	170 psi	1084 psi
Dimensional stability	ASTM D1204	0.7% maximum length change	Pass
Waterproofness	ASTM D4068	No moisture penetration	Pass
7-day shear strength	ASTM C482	50 psi	87 psi
7-day water immersion shear strength	ASTM C482	50 psi	77 psi
4-week shear strength	ASTM C482	50 psi	96 psi
12-week shear strength	ASTM C482	50 psi	90 psi
100-day water immersion shear strength	ASTM C482	50 psi	120 psi
Water vapor permeance	ASTM E96		0.75 perms
