Specifications
reinforcement waterproof1,Could be used on concrete, stick and steel.
2,Hot-resistance
3,Guarantee for 15 years
WATERPROOFING MATERIALS
Roofing membrane, consisting of a non-woven polyester reinforcement, coated with elastomer bitumen.
Membrane resists to flying fire according to the Scandinavian Nordtest NT-006
TYPE
YG-5
: top finished with a mechanically rolled slate layer
: underside finished with a thermofusible film
APPLICATION
Single layer system or double layer system
COMPOSITION
Reinforcement: 180 gr. polyester composite reinforcement
Coating mass : elastomer bitumen, consisting of ± 88% bitumen and ± 12%
styrene-butadiene-styrene (SBS)
TECHNICAL SPECIFICATIONS (average values)
Tensile strength (U.E.A.t.c.)longitudinal:1000 N / 5 cm
transversal:900 N / 5 cm
Elongation at break (U.E.A.t.c.)longitudinal:45 %
transversal:45 %
Low temperature flexibility (U.E.A.t.c.):- 25°C
Nail holding strength (U.E.A.t.c.)longitudinal:160 N
transversal:160 N
Softening Point (Ring & Ball) ASTMD.36.70: 120 °C
DIMENSIONS
Thickness:4,5 mm
Length:8 m
Width:1 m
Surface:8 m²
Average weight: kg
FIXING
Mechanical Fixing / Torching
APP/SBSPOLYESTER WATERPROOF MEMBRANE
N |
ITEM |
STANDARD |
TEST RESULT |
|
|
|
|
1
|
WATER IMPERMEABILITY |
PRESSUREMpa |
>0.3 |
NO IMPERAMEABILITY |
|
|
KEEPING TIME, min |
120MIN |
|
||||
2 |
TENSION N/5cm |
≥300 |
MEET ASTM-D5147 |
|
|
|
3 |
FRACTURE ELONGATION,% |
≥450 |
LONGTIUDINAL550.0 TRANSVERSE 510.0 |
|
|
|
4 |
SOFTEN POINT |
110°C,
|
MEET ASTM-D 5147 |
|
|
|
5 |
COLD FLEXIBILITY |
≥0(-20) |
MEET ASTM-D 5147 |
|
|
|
|
|
|||||
6 |
ELONGATION |
≥45 |
47 |
|
|
|
7 |
APP/SBS WATERPROOF MEMBRANE MEET DEMAND OF ASTM STANDARD |
|||||
