1.0mm Pitch electrical IDC connector 02-14 poles
- 100000 Piece / Pieces per Month
- HONGKONG
- T/T L/C D/P D/A
- Acrel 868MHz LoraWAN communication RS485 communication interface intelligent wireless communication terminal AWT100-LW868
- Acrel wireless communication terminal GPS location Din Rail Mounted RS485 communication interface AWT100-GPS
- Acrel AWT100-LoRaHW LoRa communication intelligent gateway Din Rail Mounted RS485 communication interface
- Acrel AWT100-WiFiHW smart gateway WiFi communication Din Rail Mounted RS485 communication interface
- Acrel 4G communication Din Rail Mounted RS485 communication interface AWT100-4GHW smart wireless communication terminal
- Acrel AWT100-CEHW wireless communication terminal Ethernet communication Din Rail Mounted RS485 communication interface
Product Details
Place of Origin: | Guangdong, China | Brand Name: | SWB | Model Number: | 1000HI 1000Wa |
Product Description
Poles: 2 to 14
Pitch: 1.0mm
Current rating: 0.5A AC/DC
Voltage rating: 30V AC/DC
Temperature range: -25 to 85°C
Contact resistance: 20mΩ maximum
Insulation resistance: 100mΩ minimum
Withstanding voltage: 200V AC/minute
Pin material: brass plated
Materials: UL94V-0
Color: natural white
Item | Part No | Material | Poles | Package |
Housing | 1000HI | LCP UL94V-0 | 02-14 | 1000 Pcs/Bag |
Terminal | 1000W | LCP Bronze | 3500Pcs/Reel |
1 Packaging: Useing strong bags/boxes/cartons for package to reduce the damage during the shipments. Tape and reel packing, Clamshell packing,Pallet packing etc are available.
2 Delivery Method: by sea, by air, or express such as DHL/TNT/UPS etc.
3 Delivery Time: normally 7-14days, could be negotiable when order is urgent.
1 fully-Inspection - Products are 100% inspected before shipment
2 In case of quality discrepancy or quantity discrepancy, we will do replenishment immediately, or other better methods after negotiation, to make sure our customers could be satisfied well.
3 Solution - Find the problems, make an effective improvement, and impose more strict quality control.
4 Long term after sell service to ensure customer is satisfied.
Q:How to place a fast connector order?
A:The following tips will save your time.
- The name of the product
- Pictures and/or the data sheet for the product
- The number of rows
- The number of pins per row
- The pitch of the connector
- The height of the insulator
- The color of the insulator
- The type of material
- Any Additional Demands
Ask your engineer for details
Are you a purchaser that doesn’t work directly with the product? To place a fast connector order, you can consult the project engineer to gather these information before contacting us.
