Bitumen Tape

Specifications

Bitumen tape

  High quality Huiyuan Peel & Seal 3 metre roll of self-adhesive flashing tape. This easy to use, tough but flexible tape is suitable for general repairs and sealing use. It is weather proof and provides long lasting protection. Keep the water out!

Also available in popular 10 meter,20 meter roll with: 50mm, 75mm, 100mm, 150mm, 225mm, 300mm, 450mm & 600mm widths.

Why buy HUIYUN bitumen tape?

The strength of the facing gives resistance to puncturing and the bitumen gives flexibility and adhesion but without the problems of slump.Designed for use as flashing on flat and pitched roofs, roof valleys, parapets and chimney stacks. Also ideal for sealing around RSJ's, flues, concrete columns, roof-lights, guttering and extractor vents.

* Replacement of worn Lead Flashing
* Lead coloured - blends with existing lead
* Crease resistant
* Easy to apply

Suitable for many uses and can be used on:-

* Replacement or repair of flashing
* Guttering, down pipes, skylights
* Extensions, porches & chimneys
* Caravans & Conservatories
* Sealing parapets, valley gutters
* Seals capping bolts & roof ridges
* Roof repair of portable buildings

Note: - In cold temperatures the tape will be harder to work with and not appear to stick as well as when warm or warmed.

Storage

Store in a cool, dry place.(+5 dg C AND 25 dg C)

Overpainting

HUIYUAN Flashing tape can be overpainted with conventional decorative paints, though a little staining many occur at the edges.

Some brief guidelines for Huiyuan bitumen tape...

Ensure all surfaces are clean, dry and dust-free. Remove any loose particles and any rust with a wire brush & soft broom.

The use of gloves is recommended.

Rough, porous or friable surfaces (such as wood, cement boards, course brickwork, breeze blocks etc..) should be primed with a bituminous primer and allowed to dry in order to improve bonding strength. (we sell primer in 1ltr 2.5ltr and 5litre tins)

1. Roll out the flashing strip then cut to the required measured length
2. Remove the backing paper (peel back 150mm) and place the adhesive side to the previously prepared surface
3. To ensure a tight contact - smooth the tape down with a dry cloth, removing all the air bubbles
4. Press the tape to the surface firmly once in position
5. Repeat the steps 2-4 in 300mm to 600mm sections until the area is covered
6. If the tape is joined ensure all overlaps are greater than 25mm
7. Smooth flat all edges with a wallpaper roller or trowel
8. After use reseal pack and store upright in cool, dry condition

   Specification of bitumen tape



   Thickness	Width:	Roll Length:	Coverage:
   0.8mm,  1.0mm,  1.2mm,  1.5mm, 2.0mm	50mm	10 / 3metres	0.5 / 0.15m2
   	75mm	10 / 3metres	0.75 / 0.225m2
   	100mm	10 / 3metres	1 / 0.3m2
   	150mm	10 / 3metres	1.5 / 0.45m2
   	225mm	10 /3metres	2.25 / 0.675m2



   Technical data of bitumen tape

   ---

   No.
   1			PE	AL	N
   2	Water impermeability	Pressure,MPa     ≥	0.2	0.2	0.1
   		Retention time,min  ≥	120,water impermeable
   3	Heat resistance°C		-----	90 degree No slippage, flowing, dropping.	--
   4	Tensile force N/50mm                ≥		130	200
   5	Elongation at break,%              ≥		450	200	450
   6	Softness		-20°C,Φ20mm,3s,180°C. No crack.		--
   7	Shear performance  N/mm	Between membranes ≥	2.0 or fracture on the external agglutination section		fracture on the external agglutination section
   		Between membrane and aluminum plate ≥
   8	Peel strength,N/mm            ≥		1.5 or fracture on the external agglutination section		fracture on the external agglutination section
   9	Puncture resistance			water impermeable
   10	Aging by artificial climate	Appearance		No crack, no bubble.	---
   		Tensile force retention percentage,%		80	---
   		Softness at low temperature,°C		-10°C,Φ20mm,3s,180°C, No crack.	---
