Help Center36W/18V High Power PoE Injector
Related Products
-
48W/24V High Power PoE InjectorUS$ 35 - 73MOQ: 10 Pieces -
IEEE 802.3at 60W Ultra Power PoE InjectorUS$ 97 - 150MOQ: 10 Pieces
-
17W/56V 1 Port Gigabit PoE Injector for IP Phone, IP Cam, AP, Security & Networking DevicesUS$ 35 - 74MOQ: 10 Pieces
-
24W/48V 1 Port Gigabit PoE Injector for IP Phone, IP Cam, AP, Security & Networking DevicesUS$ 30 - 67MOQ: 10 Pieces
-
18W/18V 1 Port Gigabit PoE Injector for IP Phone, IP Cam, AP, Security & Networking DevicesUS$ 30 - 69MOQ: 10 Pieces
Part number: POE-HIJ-3618NN4
Description: 36W/18V output , No optional function, power feeding by 4 pins
Application
- IP Phone
- IP Camera
- Access Point
- Door Security
- Security CAM
- Network terminals which require high power feed. (IPC, POS…..etc.
- WiMAX BS/CPE
- Mini Notebook PC
RJ-45 Connector and Pin-Out
|
RJ-45 Input (Data Only |
RJ-45 Output (Data & Power) |
||
Pin |
Symbol |
Description |
Symbol |
Description |
1 |
Rx+ |
Data Receive |
Rx+ |
Data Receive |
2 |
Rx- |
Data Receive |
Rx- |
Data Receive |
3 |
Tx+ |
Data Transmit |
Tx+ |
Data Transmit |
4 |
NC |
Not Connected |
-Vdc_return(+) |
Feeding power(+) |
5 |
NC |
Not Connected |
-Vdc_return(+) |
Feeding power(+) |
6 |
Tx- |
Data Transmit |
Tx- |
Data Transmit |
7 |
NC |
Not Connected |
-V dc |
Feeding power(-) |
8 |
NC |
Not Connected |
-V dc |
Feeding power(-) |
>>>" href="http://message.china.cn/msgsend/contact.htm?action=contact_action&domain=2&id=230306189&id_f=IDX1JOwVC8_mShyzFqh5j65cioCBGZIYP6-BxdiEqrkuxJUWt1KC7wOJymVzQxeDMl2s&mloca=main_site_contacts&umidToken=B3a41a2559deec3e948e90172809a27b0" target="_blank">Contact us now >>>>
Package
Number of unit in one Carton |
50 |
Weight and Volume with Power cord |
N.W.:21Kg. G.W.:22Kg. 2.1Cuft |
White Box Dimension |
21 x 8 x 6 (L x W x H) cm |
Weight of Unit / Weight of White Box |
210g / 390g |
We ship whatever you ask, by DHL/UPS/FEDEX/EMS, air or oceanshipment.
Accept small, trial orders, and costomised orders too!
Please note: All of our product's delivery term is: Ex-work Taiwan, the FOB pricing is for reference only
If there is any product information needed, please contact us or consult online
>>>" href="http://message.china.cn/msgsend/contact.htm?action=contact_action&domain=2&id=230306189&id_f=IDX1JOwVC8_mShyzFqh5j65cioCBGZIYP6-BxdiEqrkuxJUWt1KC7wOJymVzQxeDMl2s&mloca=main_site_contacts&umidToken=B3a41a2559deec3e948e90172809a27b0" target="_blank">Contact us now >>>>
MITS is a Taiwanese Company has more than 20 years of trading experiences with clients all over the world.
Any kind of customizing product projects are welcome. Please feel free to contact us for product details.
