80W Ultra Power One Port DC Input POE Injector
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Model Number:
POE UIB Series
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Unmanaged 4,8, 12 Port Multiport POE Midspan, MITS Taiwan, Rack Mountable, AC Input, Surveillance Applications, IEEE802.3NegotiableMOQ: 1 Unit -
8 16 24 Port Managed With IEEE 802.3 af Detection of Mutitiport POE Injector, MITS Taiwan, Rack Mountable, IEEE802.3at StandardNegotiableMOQ: 1 Unit
-
Web Managed 8 Port , 16 Port POE Midspan With IEEE 803.af or IEEE802.3 at Detectoion, MITS Taiwan, Rack Mounted, DC & AC InputNegotiableMOQ: 1 Unit
-
SAD 5KA Standard POE Surge ProtectorNegotiableMOQ: 1
-
Gigabit Standard POE SplitterNegotiableMOQ: 1
Place of Origin
Taiwan, China
Model Number
POE UIB Series
Specs:
*Input Voltage DC 36V ~ 72V ; Normal = DC 48V
*Input Current (60W)
1.2.1A at 36Vdc @ Full Load
2.1.6A at 48Vdc @ Full Load
3.1.05A at 72Vdc @ Full Load
*Input current(80W)
1.2.3A at 36Vdc @ Full Load
2.1.7A at 48Vdc @ Full Load
3.1.1A at 72Vdc @ Full Load
*Output Voltage +56V
*Efficiency 80% min. at Full Load, DC 36V~72V Input Voltage
*PoE detection: 60W(No), 80W(IEEE 802.3 at detection)
* Short circuit and Over voltage protection
* Over current limits
* Input has fuse protection
*EMC FCC Class B, EN55022 Class B
*Operation Temperature -25 ~ +50 ºC
*Storage Temperature -40 ~ +80 ºC
