bottle filler/bottle washing filling/rinser machine/water bottling machine
- 10 Set / Sets per Month
- shanghai
- T/T
You May Like
-
filling capping machine/mineral water plant/automatic filler/bottled drinking water
-
water production line/drinking lines/factory mineral water/bottling machinery
-
pet filling line/small bottle water plant/pure water processing line/water line production
-
bottling water plant/filling equipment/water bottling plant/water plant systems
-
automatic capping machine/beverage line/bottled water equipment/bottle manufacturer
-
factory machine/bottled water packing line/liquid energy machine/pet bottle plant
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Other | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220V/380V/415V/440V | Power | 5-15kw | |
| Place of Origin | Jiangsu, China | Brand Name | kingwan | |
| Model Number | XGF | Dimension(L*W*H) | 2200X2100X2200MM | |
| Weight | 2000-5000kg | Certification | CE SGS | |
| After-sales Service Provided | Engineers available to service machinery overseas |
wooden
Product Description
bottle filler/bottle washing filling/rinser machine/water bottling machine
Main Features
1. The water filling machine is automatic.It’s of many advantages, such as compact structure, perfect control system and easy to be operated. Advanced touch screen and PLC control system makes man-machine communication true.
2. Washing part in the bottle water machine is mainly composed of washing pump, bottle clamps, water distributor, up turn-plate, guide rail, protection cover, spraying device, defrosting tray, rinse water take and rinse water refluxing tank.
3. Filling part in the water filling machine is composed of filling barrel, filling valves (normal temperature and normal pressure filling), filling pump, bottle hanging device / bottle pedestals, elevating device, liquid indicator, pressure gauge, vacuum pump, etc.
4. Capping part in this water filling machine is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.
Main Technical Parameters
Model | Washing heads | Filling heads | Capping heads | Capacity(b/h) 500ml | Motor power (KW) | Overall dimension (mm) |
CGF14-12-5 | 14 | 12 | 5 | 4000 | 1.5KW | 2100x1400x2500 |
CGF18-18-6 | 18 | 18 | 6 | 6000 | 2.2KW | 2460x1720x2650 |
CGF24-24-8 | 24 | 24 | 8 | 10000 | 3.5KW | 2700x2100x2650 |
CGF32-32-10 | 32 | 32 | 10 | 12000 | 5.5KW | 3200x2500x2650 |
CGF40-40-10 | 40 | 40 | 10 | 16000 | 7.5KW | 4300x1800x2650 |
CGF50-50-12 | 50 | 50 | 12 | 20000 | 9.5KW | 5200x4500x3400 |
CGF60-60-15 | 60 | 60 | 15 | 25000 | 12KW | 6200x4500x3400 |
Main Pictures
washing part
filling part
capping part
Our Service
One year warranty for the whole system .
Free equipment installation and debugging.
After one year , we can help you to maintain the machine and the accessories are provided only one the cost price.
We can provide internship service and help you train the operator and mechanic.
Free production technology and process configuration.
We can help you to design the product line , workshop and provide turn-key project.
Contact information
Website:
WhatsApp/Tel:008613962267321
Skype:Kingwan8881
Alibaba TradeManager :cn1514722664vksi
water filling machine water filling machine water filling machine
water filling machine water filling machine
water filling machine water filling machine
water filling machine water filling machine
water filling machine water filling machine
Company Profile
Jiangsu kingwan Machinery Co., Ltd. is committed to the development of beverages, plastics machinery, hardware, electrical and mechanical equipment and other industries, specializing in concentrated beverage, plastics machinery and hardware, electrical and mechanical equipment research, development, manufacturing and sales, with the company's strong technical force and economic strength, and constantly develop new products with international advanced level of technology. The company is headquartered in Zhangjiagang, service network throughout the country. The company implemented network management, relying on advanced computer-aided design system and computer management system, standardized operation, in the shortest possible time to provide users with high-quality products. Companies in the technology leadership, first, customer-oriented principle to provide customers with satisfactory services. jiangsu kingwan Machinery Co., Ltd., have Zhangjiagang City wanjin Machinery Co., Ltd. specializing in the production of beverage equipment research, production, manufacture, Zhangjiagang City Plastic Machinery Co., specialized in plastic machinery research, development, manufacture, also has engaged in Research hardware, mechanical and electrical equipment production and manufacturing. Since its inception, proactive, innovative, with a good reputation, unique management style and strong marketing capabilities, has made one after another impressive performance. Over the years, rapid development of robust jiangsu kingWan Machinery Co., Ltd., inseparable from the industry's very best partners.
