small scale wheat flour mill machine
- 100 Set / Sets per Month
- Qingdao or as required
- T/T L/C D/P D/A Credit Card PayPal
- Automatic Maize Flour Mill Wheat Corn Flour Milling Machine Maize Mill
- Automatic 20tpd Wheat Maize Corn Semolina Rice Roller Flour Griding Machine Wheat Flour Mill Milling Machine
- Wheat Rice Grain Grinder Flour Mill Milling Machine For Home Use
- Widely Used Wheat Rice Grain Grinder Flour Mill Milling Machine
- Small Scale Corn Grinder Mill Machine Grain Crusher Mill Making Machine
- High Quality Grinding Mill Machine for Maize Wheat Soybean
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | 6F2240 , 6F2250 |
Model Number: | CHENGLI | Production Capacity: | 5 tonnes per day | Voltage: | 220v/380v(adjusted) |
Power(W): | according to your capacity | Weight: | according to capacity | Dimension(L*W*H): | according to capacity |
Certification: | ISO9001 BV | Warranty: | 1 years | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
small scale wheat flour mill machine
Part I . Overview
1. Capacity: Wheat:300-400kg/h
2. Main products :wheat flour
3. Power consumption : 17.2kw/h
4. Packing size : 2800x1000x3500mm
Part II. Productive technology
1. Lifting technology
The machine is pneumatic lifting for the reason of high pressure air blower application.
2. Milling technology
Use the roller mill
Part III The whole view
Part IV
Model | Capacity (kg/h) | Power (kw) | Weight (kg) | Size (mm) | Package dimension (mm) |
6F2250 | Wheat : 300-400 | 17.2 | 1500 | 2600x850 x3300 | 2800x1000x3500 |
Three-in-one cleaner | 500-600 | 3 | 100 | 1300x700 x1900 | 1400x1000x2000 |
The introduction of the flour mill
Put the clean grains into the hopper at the left side and the material will be transported to the roller mill where wheat /corn will be grinded by two units of iron roller . Then go into the sifting sieve, only the flour which is finer than the sieves can pass through the sieve and those that coarser than the sieve will go back to the roller mill and be grinded once more until passing through the sieving machine.
The details show
With a manufacturing factory which covers more than 2000 square meters, CHENGLI aims to offer the first-rate design work, high quality machinery and perfect technology serving system to customers.
We employ approximately 20 technicians to design, manufacture, install and commissioning turnkey projects for both the domestic and overseas market. We carry out a strict quality management system in accordance with ISO9001 requirements and provide a coordinated-process service including the plant layout, the process flow and the instillation technical guidance. we have been providing OEM service and customized products for our customers. We not only have a ready market in China , but also export our products all around the world including Russia , Vietnam, Kenya, Mozambique, Uganda, Ethiopia ,Nigeria , Egypt,India and so on .
