Factory direct supply oil press machine oil press plant oil press mill
- 200 Set / Sets per Month
- Qingdao/Shanghai
- T/T
- used for stone pe-250x400 quartz small jaw crushers
- low comsuption mini rock diesel engine jaw crusher
- china manufacturer provide used jaw crusher price
- high efficiency pe 400 x 600 old mini jaw crusher for sale
- manufacturer provide toggle platepe 150x250 jaw crusher machine
- pe 400x600 mobile jaw crusher price with spare parts
Product Details
Condition: | New | Usage: | Peanut Oil | Type: | Other, Cold & Hot Pressing Machine, screw press machine |
Automatic Grade: | Automatic | Production Capacity: | 200-300kg/h | Place of Origin: | Henan, China |
Brand Name: | chengli | Model Number: | 6YL-120 | Voltage: | 380V, 6 level, 11KW |
Power(W): | 3kw | Dimension(L*W*H): | 2050*1350*2000mm | Weight: | 260kg |
Certification: | ISO9001:2008, BV,ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
oil press machine
6YL-100,130,160 type oil press is a new improved product of our company. Adopting micro-motor control vacuum filter and grade-3 squeeze, it can be used for either hot press or cold press. Therefore, it is an ideal device for individual oil pressing.
Parameter
Model | Speed(r/min) | Speed ratio of gear box | Dimension(mm) | Capacity(kg/h) | Oil press | Air pump | Heater |
6YL-100 | 30-40 | 15/40*15/55=1:9.78 | 1950*1300*1900 | 150-250 | Y160M-6-7.5KW | Y90S-4-1.1KW | 3KW |
6YL-120 | 30-40 | 15/34*15/55=1:9.59 | 2050*1350*2000 | 200-300 | Y160L-6-11KW | Y100L-6-11KW | 3.5KW |
6YL-130 | 28-40 | 15/38*19/48=1:7.38 | 2200*1600*2150 | 250-400 | Y180L-6-15KW | Y180L-4-2.2KW | 3.8KW |
6YL-160 | 28-40 | 15/38*15/52=1:8.78 | 2500*1600*2500 | 400-600 | Y200L-6-18.5KW | Y200L-6-18.5KW | 4KW |
Screw oil press working principle:
Crudeoil →degumming→filtration→deacidification/deodorization→filtration→refining of crude palm kernel oil
1.When oil press is on work, material enters the extruding chamber from the hopper and then moves forwards by the rotating pressing screw and is pressed.
2.Under high temperature condition in the chamber, there is quite strong friction among press screw, chamber and the oil materials.
3.On the other hand, root diameter of the pressing screw carries larger from one end to the other.
4.Hence when rotating, the thread not only pushes particles moving forwards but also turns them outwards as well.
5.Meanwhile, particles adjacent the screw will rotate along with screw’s rotating, causing every particle inside the chamber to possess different speed.
6.Therefore, relative movement among particles creates neat which is necessary during manufacturing because of helping protein change property, damage colloid, increase plasticity, decrease oil’s elasticity, resulting in high oil.
Raw Material | Capacity (kg/hr) | Output Rate (%) | Cake Residual (%) |
Rape seeds | 80-100 | 30-35 | 7.5-8 |
Ground nuts | 80-100 | 35-45 | 7 |
Beans | 75-95 | 10-14 | 6.5-7 |
Sesame | 80-100 | 44-47 | 6.5-7.5 |
Cotton seeds | 40-50 (cold press) | 10-14 | 5.5-6.5 |
As a professional manufacturer of grain processing machineries, Henan Chengli Grain & Oil Machinery Co., Ltd has been catering to various wheat and maize milling and other grain processing needs of clients since found by providing top class solutions. In the past many years, we have made a long-term development relying on our solid technology, scientific management, advanced facility as well as good after-sale service. Taking the researching and manufacturing of top grade grain machinery as its responsibility, cooperating with many scientific research institution and universities, we attach the importance to the talents and advanced technology introduced from the outside world. Moreover, we have made the marketable products of new and high quality management system. We not only have a ready market in China, but also export our products all around the world including Russia, Vietnam, the Philippines, Australia, Mexico, Bangladesh, India and African countries.
Our company can supply the technology and service on complete corn deep-processing set, complete deep flour milling set, single corn pelling machine, single corn grinding machine, single corn polishing machine, single different kinds of pulverizer, single different kinds of sieve and plansifter, single centrifugal ventilator and other machinery parts . we can supply the different designs with different cost to meet different buyer's requests.
1.Expected installation time: about 25-30 working days for 2 engineers;
2.Training: we offer free training of your workers during the time of installation;
3.Warranty Period: one year after the date of successful commissioning;
4.24 hours rapid response for full-time;
5.OEM
