Beijing Jinghua Park Polyurethane Equipment Co., Ltd freshly launched JHPK-F2008A polyurethane spray and injection equipment, which has more advanced configuration, higher heating power, lighter weight and better mobility than other types.
Various types of double-component spray guns provide more selections for you. You can realize the transformation between spraying and injection only by changing the gunpoint, dispensing with changing other parts of the equipment. It makes the operation very easy.
The respective 3000w heaters foe the double-component materials reduce the viscosity of the material more effectively to assure the optimal blending effectiveness.
The automatic reposition devices postpone the use time of materials sealing parts by reposting the transfer pump down to the stop point at the end of each working day.
The changeable power heating temperature control prevents overheating effectively. The safety steps for whole process temperature control, overheating control and emergency stop make the operation easy and safe.
The new JHPK-F2008A system can be widely used in different kinds of areas such as refrigerator warehouse heat preservation, building external wall, roof water-proof and heat preservation, gymnasium, motorcar and ship, air conditioner adiabatic, and solar water heater and so on.
Standard Configuration:
| Mainframe | 1 set |
| Spray gun | 1 set |
| Heating and preserved pipe | 15m |
| Connecting pipe for spray gun | 1.5m |
| Max. length (optional) | 90 meter |
| Transfer pump | 2 sets |
| Academic max. output of material pump | 9.5kg/min(21b./min) |
| At operating pressure material output | 4~8kg/min |
| The highest heating temperature | 80℃ |
| Heating device power for material | 3000w x2(or 4500w x2optional) |
| Heating power for pipe heating preservation | 3500w |
| Single material output output pressure | 11Mpa(1600psi) |
| Max. Pipe length | 90m(300Ft) |
| The highest heating temperature | 80℃ |
| Air source requirements | 0.9m3/min 0.7Mpa(33cfm,100psi) |
| Electrical requirements | 3-phase,380v, 50Hz ,it can changed according to customers’ demand by charging some fee . |
Shipping Parameter:
Volume: 900*800*1550(mm)
Weight: 260kg
Payment term : 100% T/T in advance
Trade term : EXW or FOB or CFR or CIF Tianjin
Packing details : plywood tray ; it can be transported to any country directly without other new packaging .
Delivery time :we always have our machine in stock ,so we will ship the machine when the payment is confirmed if customers’ do not need the change the voltage ; and it will needs about fifteen working days to change the voltage if it is needed .
Mini order : only one set ;if you buy more than three sets ,you will get a very favorable price .
The equipment has obtained CE certification, safe and environmental protection.
Having the proprietary property rights in design and production, several national patents have been applied and approved.
Beijing Jinghua Park Polyurethane Equipment Co.Ltd. is a modern, dynamic and expanding Chinese private enterprise located in Beijing the capital of China.JHPK specializes in developing,manufacturing and distributing the polyurethane materials & the relevant high pressure airless polyurethane spray perfusion equipment. The wide varieties of single or double-components high temperature airtight spray polyurethane equipment can be used in many areas such as waterproof, antisepsis, construction, dope and fireproof.
JHPK and its shareholders take pride in the strict, scientific and professional management and consummate quality assurance system.With the years of production experience JHPK widely imbibed the advanced technology from China and worldwide. Especially the uses of world famous brand parts make the equipments have excellent performance.
