JHPK-PKIII Perfusion and Spraying Gun
1. Several national patents with advanced technology and reliable quality.
2. Compact and reasonable structure, manufactured with high performance lightweight material with total weight only 0.9 kg.
3. Fission type design for pneumatic part and raw material part avoiding the blocking.
4. Dual piston design providing more power which guarantees the smooth and flexible operation.
5. The special pneumatic spring design at sliding bar of the gun replaces easy-worn mechanical spring and guarantees the operation.
6. The metal abrasion protection is used so that the sealing is more reliable and enhanced the lifetime.
7. The unique auxiliary pulverization design for air drum efficiently controls the splashing and bouncing of the raw material which can save 15% of the raw material.
8. Multiple round spraying nozzle, flat spraying nozzle and perfusion nozzle can be interchanged during operation. The applicable scope is more extensive.
9. The special flat spraying mode is more suitable for the internal angle, external angle, balcony and roofing and convenient for controlling the spraying thickness and sprayed location.
10. The unique design in the protection cover reduces the frequency in gun cleaning and prolongs the lifetime for 50%.
Technical Data:
1. Max. fluid working pressure: 24 MPa
2. Air inlet pressure: 0.4-0.8 MPa
3. Air tube dia.: Φ10 X1
4. Working flow: 2-8 kg/min
5. Type of nozzle: round, flat and perfusion
6. Cleaning method: self cleaning with air
