Specifications
Meta-Aramid Fiber1.Material: 100% Meta Aramid Fiber
2.Length:51mm
3.Pattern: Raw or dyed
Meta-Aramid Fiber, Aramid Fiber, Aramid
Meta aramid fibers are a class of heat resistant and strong synthetic fibers. They are used in aerospace and military applications, for ballistic rated body armor fabric and ballistic composites, in bicycle tires, and as an asbestos substitute. They are fibers in which the chain molecules are highly oriented along the fiber axis, so the strength of the chemical bond can be exploited.
Detection report of PMIE2.22dtex*51mm
| Item | Unit | Average | Min | Max | Industrial Standard |
| Linear Density | DTEX | 2.26 | 2.06 | 2.44 | ±15% |
| Break Strength | CN/DTEX | 3.98 | 3.80 | 4.25 | ≥3.45 |
| Elongation at Break | % | 32.86 | 28.26 | 30.76 | 25~40 |
| Number of Crimps | per 25mm | 9.06 | 8.00 | 12.60 | 8~14 |
| Crimpness | % | 12.13 | 10.1 | 17.8 | 10~18 |
|
Dry Thermal Shrinkage 300°C*15min |
% | 2.60 | 0.98 | 2.97 | ≤5 |
| Oil Content | % | 1.05 | 0.50 | 1.30 | --- |
| Moisture Regain | % | 6.10 | 4.3 | 7.60 | 6~9 |
The oil content can be adjusted from 0.4~1.5% besed on customers' specific requirements.
|
Properties
|
|
1.good resistance to abrasion |
|
| 2.good resistance to organic solvents | |
| 3.nonconductive | |
4.no melting point, degradation starts from 500°C |
|
5.low flammability |
|
6.good fabric integrity at elevated temperatures |
|
| 7.sensitive to acids and salts | |
| 8.sensitive to ultravioletradiation |
|
Industrial Uses
|
|
1.flame-resistant clothing |
|
2.heat protective clothing and helmets |
|
3.body armor, competing with PE based fiber products such as Dyneema and Spectra |
|
posite materials |
|
| 5.asbestos replacement | |
6.hot air filtrationfabrics |
|
7.tires, newly as Sulfron |
|
chanical rubber goods reinforcement |
|
9.ropes and cables |
|
10.wicks for fire dancing |
|
11.optical fiber cable systems |
|
12.sailcloth (not necessarily racing boat sails) |
|
13.sporting goods |
|
14.drumheads |
|
d instrument reeds, such as the Fibracell brand |
|
16.loudspeaker diaphragms |
|
17.boathull material |
|
18.fiber reinforced concrete |
|
19.tennis strings, snowboards and hockey sticks |
|
Other related Aramid Fiber :
Aramid Fiber Yarn for Weaving
If you have any questions about aramid fiber, please feel free to contact us.
