China Supplier steel i beams for sale sizes i shape steel Q235B

FOB Price

USD $390 - $500 / Ton

1 Ton(Min.Order)

Supply Ability 5000 Ton / Tons per Month
Port Tianjin Port China
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Get lowest price Inquiry Basket

You May Like

Product Details

Place of Origin:	Tianjin, China	Grade:	SS400	Technique:	Hot Rolled
Thickness:	6-28mm	Application:	Construction	Length:	6-16m
Standard:	ASTM	Flange Width:	100-314mm	Flange Thickness:	1-30mm
Web Width:	96mm - 1056mm	Web Thickness:	6-21mm	Brand Name:	Emerson
Model Number:	H-Beam

Product Description

China Supplier steel i beams for sale sizes i shape steel Q235B

1. Product Description

H-Beam is another product coming out from our hot rolled mill.It is the structural steel profile shaped like an H in section.The horizontal elements of the "I" are flanges,while the vertical element is the web.The web resists shear forces while the flanges resist most of the bending moment experienced by the beam.Beam theory shows that the H-shaped sections is a very efficient form for carrying both bending and shear loads in the plane of the web.
H-Beam are widely used in the construction industry and are available in a variety of standard sizes. H-Beam may be used both as beams and as columns.

China Supplier steel i beams for sale sizes i shape steel Q235B

2.Specification

Products Name	China Supplier steel i beams for sale sizes i shape steel Q235B
Grade	Q235B,SS400,Q345B,S235JR,S275JR,ASTM-A36
Size	100x100mm-900x300mm
Thickness	10-28m
Length	6-12 meters
Shap	H-shaped or H-channel
Delivery Time	7-15 Days if in stock size, or it will be 20-40 for customized
Payment Term	L/C or T/T
Package	By bundle or as customer's requirement
Application	Engineering or project, plant and equipment, mechanical equipment, bridge, etc
Surface	Black, coating, galavnized
Finish	Hot rolled
MOQ	1 Ton

China Supplier steel i beams for sale sizes i shape steel Q235B

3.Chemical Composition for reference

C	Si	Mn	S	P	Cr	Ni	Cu
0.17-0.22%	≤0.35%	0.3-0.7%	≤0.045%	≤0.045%	≤0.030%	≤0.030%	≤0.030%

China Supplier steel i beams for sale sizes i shape steel Q235B

4.Sizes as referance

China Supplier steel i beams for sale sizes i shape steel Q235B
(H-Height, B-Breadth, T1-Web thickness, T2-Flange thickness)
Category	Size	H*B(mm)	T1(mm)	T2(mm)	Weight(kg/m)
HW	100*100	100*100	6	8	17.2
	125*125	125*125	6.5	9	23.8
	150*150	150*150	7	10	31.9
	175*175	175*175	7.5	11	40.3
	200*200	200*200	8	12	50.5
	200*200	200*204	12	12	56.7
	250*250	250*250	9	14	72.4
	250*250	250*255	14	14	82.2
	300*300	294*302	12	12	85
		300*300	10	15	94.5
		300*305	15	15	106
	350*350	344*348	10	16	115
	350*350	350*350	12	19	137
	400*400	388*402	15	15	141
		394*398	11	18	147
		400*400	13	21	172
		400*408	21	21	197
		414*405	18	28	233
		428*407	20	35	284
		458*417	30	50	415
		498*342	45	70	605
HM	150*100	148*100	6	9	21.4
	200*150	194*150	6	9	31.2
	250*175	244*175	7	11	44.1
	300*200	294*200	8	12	57.3
	350*250	340*250	9	14	79.7
	400*300	390*300	10	16	107
	450*300	440*300	11	18	124
	500*300	482*300	11	15	115
	500*300	488*300	11	18	129
	600*300	582*300	12	17	137
		588*300	12	20	151
		594*302	14	23	175

China Supplier steel i beams for sale sizes i shape steel Q235B

China Supplier steel i beams for sale sizes i shape steel Q235B

(2)Galvanized steel plate

Galvanized steel coils cut to plate
Thickness: 0.1mm-2.5mm width: 600mm/800mm/1250mm

China Supplier steel i beams for sale sizes i shape steel Q235B

(3) Al-zinc coils and plate

China Supplier steel i beams for sale sizes i shape steel Q235B

(4)Seamless steel pipe, seamless steel tube, seamless pipe, Hollow bar sizes: outer diameter: 8mm-800mm, wall thickness: 1mm-80mm

China Supplier steel i beams for sale sizes i shape steel Q235B

(5)Galvanized steel pipe, welded steel pipe
Outer diameter: 6mm-400mm
Wall thickness:0.5mm-6mm

China Supplier steel i beams for sale sizes i shape steel Q235B

(6) Round bar
Material: S235JR, 1045, 1018, 1518, 1020, 41040, 4340, 8620 and other materials
Diameters: 3mm-800mm

China Supplier steel i beams for sale sizes i shape steel Q235B

(7)steel profile
angle bar; channel bar; h beam; rectangular tubes

7.Company Information

China Supplier steel i beams for sale sizes i shape steel Q235B

Tianjin Emerson Commercial and Trade Co.,Ltd mainly provides steel plate, steel sheet, steel pipe,seamless steel pipe and tube, round bars and steel section, and doing steel products processing service: steel plate and sheet processing service. The processing works concludes cutting the larger plate into the small sizes customer demand, cut by drawing, cut to special sizes, weld the cut parts by drawing, also make galvanizing processing or surface painting on the final processed parts; steel pipe hollow bar cutting and lathe processing to make the outer diameter and wall thickness to meet customers requirement, also make heat treatment for hollow bars and pipes. Tianjin Emerson Commercial and Trade Co.,Ltd has large stocks for the carbon steel and low alloy steel plates and sheets, especially have the thick plate and heavy plates on stock, also can provide the special material and large size steel plates, boiler and pressure vessel steel plate, marine steel plate, hot rolled steel plate for new production. Tianjin Emerson Commercial and Trade Co.,Ltd also has large stock for hollow bars, thick wall seamless pipes and tubes. Tianjin Emerson Commercial and Trade Co.,Ltd can provide good service for customer, good quality products, fast delivery, and after-sale service, Tianjin Emerson hopes to build good cooperation with everyone interested.
