China Supplier steel i beams sizes for sale h beam steel of SS400
1. Product Description
H-Beam is another product coming out from our hot rolled mill.It is the structural steel profile shaped like an H in section.The horizontal elements of the "I" are flanges,while the vertical element is the web.The web resists shear forces while the flanges resist most of the bending moment experienced by the beam.Beam theory shows that the H-shaped sections is a very efficient form for carrying both bending and shear loads in the plane of the web.
H-Beam are widely used in the construction industry and are available in a variety of standard sizes. H-Beam may be used both as beams and as columns.
China Supplier steel i beams sizes for sale h beam steel of SS400
2.Specification
| Products Name | China Supplier steel i beams sizes for sale h beam steel of SS400 |
| Grade | Q235B,SS400,Q345B,S235JR,S275JR,ASTM-A36 |
| Size | 100x100mm-900x300mm |
| Thickness | 10-28m |
| Length | 6-12 meters |
| Shap | H-shaped or H-channel |
| Delivery Time | 7-15 Days if in stock size, or it will be 20-40 for customized |
| Payment Term | L/C or T/T |
| Package | By bundle or as customer's requirement |
| Application | Engineering or project, plant and equipment, mechanical equipment, bridge, etc |
| Surface | Black, coating, galavnized |
| Finish | Hot rolled |
| MOQ | 1 Ton |
China Supplier steel i beams sizes for sale h beam steel of SS400
3.Chemical Composition for reference
C |
Si | Mn | S | P | Cr | Ni | Cu |
| 0.17-0.22% | ≤0.35% | 0.3-0.7% | ≤0.045% | ≤0.045% | ≤0.030% | ≤0.030% | ≤0.030% |
China Supplier steel i beams sizes for sale h beam steel of SS400
4.Sizes as referance
| China Supplier steel i beams sizes for sale h beam steel of SS400 | |||||
| (H-Height, B-Breadth, T1-Web thickness, T2-Flange thickness) | |||||
| Category | Size | H*B(mm) | T1(mm) | T2(mm) | Weight(kg/m) |
| HW | 100*100 | 100*100 | 6 | 8 | 17.2 |
| 125*125 | 125*125 | 6.5 | 9 | 23.8 | |
| 150*150 | 150*150 | 7 | 10 | 31.9 | |
| 175*175 | 175*175 | 7.5 | 11 | 40.3 | |
| 200*200 | 200*200 | 8 | 12 | 50.5 | |
| 200*204 | 12 | 12 | 56.7 | ||
| 250*250 | 250*250 | 9 | 14 | 72.4 | |
| 250*255 | 14 | 14 | 82.2 | ||
| 300*300 | 294*302 | 12 | 12 | 85 | |
| 300*300 | 10 | 15 | 94.5 | ||
| 300*305 | 15 | 15 | 106 | ||
| 350*350 | 344*348 | 10 | 16 | 115 | |
| 350*350 | 12 | 19 | 137 | ||
| 400*400 | 388*402 | 15 | 15 | 141 | |
| 394*398 | 11 | 18 | 147 | ||
| 400*400 | 13 | 21 | 172 | ||
| 400*408 | 21 | 21 | 197 | ||
| 414*405 | 18 | 28 | 233 | ||
| 428*407 | 20 | 35 | 284 | ||
| 458*417 | 30 | 50 | 415 | ||
| 498*342 | 45 | 70 | 605 | ||
| HM | 150*100 | 148*100 | 6 | 9 | 21.4 |
| 200*150 | 194*150 | 6 | 9 | 31.2 | |
| 250*175 | 244*175 | 7 | 11 | 44.1 | |
| 300*200 | 294*200 | 8 | 12 | 57.3 | |
| 350*250 | 340*250 | 9 | 14 | 79.7 | |
| 400*300 | 390*300 | 10 | 16 | 107 | |
| 450*300 | 440*300 | 11 | 18 | 124 | |
| 500*300 | 482*300 | 11 | 15 | 115 | |
| 488*300 | 11 | 18 | 129 | ||
| 600*300 | 582*300 | 12 | 17 | 137 | |
| 588*300 | 12 | 20 | 151 | ||
| 594*302 | 14 | 23 | 175 | ||
China Supplier steel i beams sizes for sale h beam steel of SS400
China Supplier steel i beams sizes for sale h beam steel of SS400
1. How long can make delivery?
China Supplier steel i beams sizes for sale h beam steel of SS400
For stock products, will make shipments in 5- 7 days after receiving deposit or receiving L/C; for products need new production for common materials, usually make shipments in 15-20 days; for products need new production for special and rare materials, usually need 30-40 days to make shipment.
2. Will the Test Certificate be certified to EN10204 3.1?
China Supplier steel i beams sizes for sale h beam steel of SS400
For the new production products no need furthur cutting or processing, will provide the Original Mill Test Certificate certified to EN10204 3.1; for the stock products and the products need cutting or furthur processing, will issue Certificate of Quality on our Company, It will show the original mill name and the original datas.
3. Once the received products found not comply with the products the contract demands, what will you do?
China Supplier steel i beams sizes for sale h beam steel of SS400
Once the received products found not comply with the products the contract lists, when receiving the pictures and the official documents and data from your side, if it is proved not comply, we will compensate the loss at first time.
6. Related productions
China Supplier steel i beams sizes for sale h beam steel of SS400
(1)Cold rolled steel coils cut to plate
Thickness : 0.5mm-3.0mm width : 800mm/1250mm
China Supplier steel i beams sizes for sale h beam steel of SS400
(2)Galvanized steel plate
Galvanized steel coils cut to plate
Thickness: 0.1mm-2.5mm width: 600mm/800mm/1250mm
China Supplier steel i beams sizes for sale h beam steel of SS400
(3) Al-zinc coils and plate
China Supplier steel i beams sizes for sale h beam steel of SS400
(4)Seamless steel pipe, seamless steel tube, seamless pipe, Hollow bar sizes: outer diameter: 8mm-800mm, wall thickness: 1mm-80mm
China Supplier steel i beams sizes for sale h beam steel of SS400
(5)Galvanized steel pipe, welded steel pipe
Outer diameter: 6mm-400mm
Wall thickness:0.5mm-6mm
China Supplier steel i beams sizes for sale h beam steel of SS400
(6) Round bar
Material: S235JR, 1045, 1018, 1518, 1020, 41040, 4340, 8620 and other materials
Diameters: 3mm-800mm
China Supplier steel i beams sizes for sale h beam steel of SS400
(7)steel profile
angle bar; channel bar; h beam; rectangular tubes
7.Company Information
China Supplier steel i beams sizes for sale h beam steel of SS400
Tianjin Emerson Commercial and Trade Co.,Ltd mainly provides steel plate, steel sheet, steel pipe,seamless steel pipe and tube, round bars and steel section, and doing steel products processing service: steel plate and sheet processing service. The processing works concludes cutting the larger plate into the small sizes customer demand, cut by drawing, cut to special sizes, weld the cut parts by drawing, also make galvanizing processing or surface painting on the final processed parts; steel pipe hollow bar cutting and lathe processing to make the outer diameter and wall thickness to meet customers requirement, also make heat treatment for hollow bars and pipes. Tianjin Emerson Commercial and Trade Co.,Ltd has large stocks for the carbon steel and low alloy steel plates and sheets, especially have the thick plate and heavy plates on stock, also can provide the special material and large size steel plates, boiler and pressure vessel steel plate, marine steel plate, hot rolled steel plate for new production. Tianjin Emerson Commercial and Trade Co.,Ltd also has large stock for hollow bars, thick wall seamless pipes and tubes. Tianjin Emerson Commercial and Trade Co.,Ltd can provide good service for customer, good quality products, fast delivery, and after-sale service, Tianjin Emerson hopes to build good cooperation with everyone interested.
