XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools

XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools thumbnail-1
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools thumbnail-2
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools thumbnail-3
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools thumbnail-4
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools thumbnail-5
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools thumbnail-6
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools photo-1
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools photo-2
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools photo-3
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools photo-4
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools photo-5
XZ6350Z Milling/drilling Machine, Metal Drilling Machine, Machine Tools photo-6
US$ 4,100 - 4,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
FINDMC
Contact Supplier Request Quote Chat Now
Jinan Find Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qind Dao / Shang Hai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name FINDMC
Model Number ZX6350Z
Type Universal
CNC or Not Normal
Voltage 380V 50Hz
Power(W) 2.2 KW
Dimension(L*W*H) 1520*1285*2150 mm
Weight 1350 Kg
Certification ISO9001:2008
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas



Product Description



Drilling Milling machine details









Specifications

Units

XZ6350Z

Table size

mm

1120×260

Table travel

mm

600×300

Spindle taper



ISO40

Max. drilling dia.

mm

50

Automatic drilling dia.

mm

14(cast iron)

Max. vertical milling dia.

mm

25

Distance between spindle nose and table surface

mm

100-400

Spindle speed range

rpm

90-2000(V)/38-1310(H)

Spindle travel

mm

120

Overall dimension

mm

1520×1285×2150

Spindle motor power

KW

2.2

Machine weight

Kg

1350





Accessories







N0.

Name

Model

Qty

1

Drilling milling machine

XZ6350Z(ZA, ZB)

1

2

Drill chuck

16

1

3

Inner-hexagonal spanner

5

1

4

Wedge shifter



1

5

Reduction sleeve

ISO40/MT3,ISO40/MT2

Each 1

6

wrench

S21-24

1

7

Spindle arbor



1

8

Vice

160

1

9

Milling chuck

4—16

1set

10

Horizontal milling arbor

22,27

2sets

11

Draw bar



2

12

Operation manual



1

13

Quality certificate



1

14

Packing list



1



Packaging & Shipping







Drilling Milling machine Z6350Z Type of package: Plywood case



Drilling Milling machine Z6350Z  Packing dimension:

                                    160*152*222cm (one set in one case)      N.W./G.W.: 1350/1500KG

                                     220*152*222cm (two sets in one case)    N.W./G.W.: 2700/2900KG

Suitable Container and quantity:

Standard 20' container: 3 sets         Standard 40' container: 6 sets





Delivery time: 45-60days



Payment terms: TT30% down payment, TT70% before the delivery
